V4 UNIVERSAL VANE FLOW CHARTS
Values shown in both charts are nominal. If normal flows exceed actuation rates by
less than 10%, custom vanes are recommended. Figures are based on standard
vertical installation in a 1-1/2˝ thredolet in a horizontal run of pipe.
APPROXIMATE ACTUATION/DEACTUATION FLOW RATES FOR COLD WATER - UPPER FIGURES IN GPM. LOWER FIGURES IN LPM
Vane Layers 1.5˝ Pipe 2˝ Pipe
1 7-3 15-8
26.67-11.67 56.7-30
1 and 2 7-4
26.7-15
1, 2, and 3
1, 2, 3, and 4
1, 2, 3, 4, and 5
Note: Actuation rates are based on cold water at a specific gravity of 1.0. For fluids of different specific gravity, actuation rates may be approximated by dividing the rate
shown by the square root of the specific gravity.
APPROXIMATE ACTUATION/DEACTUATION FLOW RATES FOR AIR - UPPER FIGURES IN SCFM. LOWER FIGURES IN LPS
Vane Layers 1.5˝ Pipe 2˝ Pipe
1 32-17 65-32
15-8 30-20
1 and 2 23-13
10-6
1, 2, and 3
1, 2, 3, and 4
1, 2, 3, 4, and 5
Note: Actuation rates are based on air at standard conditions. For gases at other pressures, temperatures, or specific gravities, consult factory for equivalent flow
approximations.
APPLICATION DRAWINGS FOR FLOTECT
1-1/2˝ THREDOLET
CUT HOLE IN PIPE
1-15/16˝ [49.2MM] DIA MIN
Standard Installation
3/4 NPT
ANSI RF
THREADED
REDUCING
FLANGE
*
ANSI RF
WELDING
NECK
*FLANGE FACE TO
FLANGE
PIPE O.D. SPECIFIED
BY CUSTOMER
NORMALLY SHOULD
NOT EXCEED
FLOW
Flange Installation
DWYER INSTRUMENTS, INC.
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A.
3˝ Pipe 4˝ Pipe 6˝ Pipe
45-22 95-40 210-120
167-83.3 367-150 800-450
23-14 50-35 130-90
86.7-53.3 190-132 500-333
11-7 27-19 80-60
41.7-26.7 102-71.7 300-233
17-12 60-45
65-45 233-167
40-30
152-113
3˝ Pipe 4˝ Pipe 6˝ Pipe
210-105 400-200 950-475
100-50 190-90 450-220
120-70 195-140 550-375
60-30 90-70 260-180
60-48 135-100 375-265
30-20 60-50 180-130
65-50 260-200
30-20 120-90
130-100
60-50
AUTOMATIC FLOW SWITCHES
®
5˝ [127MM]
8˝ Pipe 10˝ Pipe 12˝ Pipe
375-175 600-300 900-450
1417-667 2267-1133 3400-1700
230-150 450-250 650-350
867-567 1700-950 2467-1317
160-115 300-180 450-275
600-433 1133-683 1700-1033
120-90 230-150 310-200
450-333 867-567 1167-750
80-65 135-100 200-140
300-250 517-383 750-533
8˝ Pipe 10˝ Pipe 12˝ Pipe
1550-850 2400-1300 3450-1900
730-400 1100-600 1600-900
1100-700 1850-1200 2700-1750
520-330 870-570 1300-800
725-500 1200-850 1850-1300
340-240 570-400 870-610
500-400 875-700 1250-1000
240-190 410-330 590-470
310-250 650-525 1000-800
150-120 310-250 470-380
FLOW
1-1/2˝ X 1-1/2˝ X 1-1/2˝
Tee Installation
FLOW
2˝ X 2˝ X 2˝
Tee Installation
Phone: 219-879-8000
Fax: 219-872-9057
14˝ Pipe 16˝ Pipe 18˝ Pipe
1200-600 1400-800 2000-1000
4550-2267 5300-3033 7567-3783
900-500 1200-650 1450-800
3400-1900 4550-2467 5483-3033
600-350 750-450 1000-600
2267-1317 2750-2083 3783-2267
430-280 550-360 700-450
1633-1067 2083-1367 2650-1700
290-200 360-250 460-325
1100-750 1367-950 1733-1233
14˝ Pipe 16˝ Pipe 18˝ Pipe
4700-2600 6400-3500 8000-4400
2200-1200 3000-1700 3800-2100
3400-2200 4800-3100 6000-3900
1600-1000 2300-1500 2800-1800
2600-1800 3350-2350 4300-3000
1200-800 1600-1100 2000-1400
1900-1500 2500-2000 3100-2500
900-710 1200-900 1500-1200
1600-1250 2200-1750 2800-2250
760-590 1040-830 1300-1100
2-1/2˝ X 1-1/2˝ FACE
OR HEX BUSHING
2-1/2˝ THREADED FACTORY INSTALLED
BRANCH
CONNECTION
CUT HOLE IN PIPE
2-7/8˝ [73MM]
2-1/2˝ Thredolet Installation
3/4 NPT
1-1/2˝ 3000 LB.
COUPLING
2-1/16˝ [52.4]
BORE I.D.
Line
Pipe
Size Dim A
2˝ 2-5/8 [66.7]
3˝ 2-1/2 [63.5]
4˝ 2-7/16 [61.9]
Not recommended unless
coupling is bored out to 2-1/16˝ [52.4] as shown
www.dwyer-inst.com
