8"(203mm)
Mounting
Template
CAUTION:
To avoid potential personal injury or property damage:
All 6 lag bolts
MUST BE firmly tightened to prevent unwanted movement of the wall plate
assembly. Ensure the wall plate assembly is securely fastened to the wall before continuing on to
the next step.
To prevent the TV falling down, the Bolt Head Must Keep UP at this step!!
Concrete Wall
Solid Concrete or Concrete Block Installations
Min.
8"(203mm)
8"(203mm)
16"(406mm)
Anchor
IMPORTANT: Never drill into
the mortar between blocks.
3/8"
(10mm)
Bolt Head
UP!
DANGER
2.9"
(74mm)
