Tesla SMART AIR PURIFIER MINI Benutzerhandbuch Seite 4

2.Standby
Insert the plug of air purifier into power source, the buzzer will ring, and all the indicators will
lighten. After three seconds, air purifier is in standby mode, indicator lights up, and the other
icons do not lights up.
3. Power on/off
Tap the top power icon to switch the power on and off, the default wind speed is low, and
the child lock is off (negative ion off)
4. Speed button
Wind speed adjustment "Low " → "High"→ "Sleep", Loop in turn. (Low match).
5. Anion/Negative Ions
Touch the negative ion icon to turn the negative ion function on or off.
6. Replace the filter
When the air purifier is turned on, it will count down, turn off the air purifier and restart, it will
continue to count down. When the filter replacement is accumulated for 2000 hours, the
replacement filter indicator light will flash, and the buzzer will beep. After replacing the new
filter, keep pressing the filter reset icon for three seconds icons light fully light up and do not
flash. At the same time the buzzer is turned off.
7. Timing Function
Touch the timing icon, adjust the countdown shutdown time 1H 2H 4H 8H Loop in turn.
8. Sleep stalls
Touch the wind speed adjustment icon, adjust to the sleep gear position, enter the sleep
mode, all the lights are off, only the wind speed icon light and the sleep gear light are half
bright, touch the wind speed icon to exit the sleep mode.
9. Auto Function
Touch auto mode, it automatically checks the content of particles in the air near the machine,
At the same, it displayd by the light in the machine according to the surrounding air quality.
There are 4 colors of air quality indicator, which are blue, green, purple and red. Blue re-
present the content of particulate matter in air of 0-50 ug/m3 (Excellent), green represents
51-100 ug/m3 (Good), purple represents 101 - 150 ug/m3 (Normal) and the red color
represents the content of the particloes in the air is more then 151 ug/m3 (Poor)
INSTRUCTIONS
Before you turn on the machine for the first time, be sure to remove the filter bag before you
use it.
1. Air purifier filter installation
Grasp the bottom cover handle by hand (the position shown by the arrow in Figure 1) and turn
the bottom cover in the direction of unlocking. Then take out the filter (the item shown by the
arrow in Figure 2), remove the filter bag, and put the filters back, then insert the bottom cover
into the fuselage and turn it in the direction of the lock.
4
