All manuals and user guides at all-guides.com Bedienungsanleitung Instructions for use Notice d‘emploi Istruzioni per l‘uso Instrucciones para el uso Gebruiksaanwijzing...
Seite 3
All manuals and user guides at all-guides.com 908 B / 908 D / 908 B ew / 908 T ew Diese Mikrofone sind professionelle dauerpolarisierte Kondensator-Mikrofone. Ihr weiter Dynamikumfang und der sorgfältig abgestimmte Frequenzgang sorgen für ausgezeichnete Signalqualität mit Durchsetzungsvermö- gen und hoher Verzerrungsfreiheit.
Seite 4
All manuals and user guides at all-guides.com Mit den langen, flexiblen Schwanenhälsen können die Mi- krofone optimal am Instrument ausgerichtet werden. Merkmale außergewöhnlich lebendiger und klarer Klang langer, flexibler Mikrofonarm zur optimalen Ausrichtung am Instrument unempfindlich gegen Tritt- und Körperschall durch federnde Kapsellagerung Metallgehäuse reißfestes Kabel...
Seite 5
All manuals and user guides at all-guides.com Mikrofon platzieren Blasinstrumente ( 908 B / 908 B ew / 908 T ew) Positionierung Klangresultat Kommentar reduzierte Mikrofon mit der Nebengeräusche Klammer MZH 908 B am Trichter des In- struments befesti- gen und direkt auf den Schalltrichter ausrichten.
Seite 6
All manuals and user guides at all-guides.com Schlagzeug/Percussion ( 908 D) Positionierung Klangresultat Kommentar viel Grundton, Positionierung an wenig Obertöne der Trommel: 3 – 5 cm über dem Fell, Ausrichtung zur Fell- mitte. Das Verhält- nis von Grundton zu Obertönen lässt sich wenig Grundton, mit dem Winkel ein- viel Obertöne...
Seite 7
All manuals and user guides at all-guides.com Schlagzeugklammer an der Trommel befestigen Schlagzeug/Percussion ( 908 D) Positionierung Kommentar Die Schlagzeugklammer MZH 908 D wird durch Aufschnappen auf den Spannreifen der Trommel befestigt. Führen Sie zunächst den oberen Schnapper auf den Spannreifen (1) und rasten Sie dann die Schlagzeugklammer nach unten ein (2).
Seite 9
All manuals and user guides at all-guides.com Optimale Positionierung des Mikrofons Die vielfältigen Einstellmöglichkeiten der Klammern MZH 908 D und MZH 908 B in Verbindung mit dem flexi- blen Schwanenhals bieten Ihnen die Möglichkeit, das Mi- krofon optimal an der Schallquelle zu positionieren (siehe Pfeile der Abbildungen).
Seite 10
All manuals and user guides at all-guides.com Polardiagramm 0° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 2000 Hz 125 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Frequenzgang - 30 - 40 - 50 - 60 - 70...
Seite 11
All manuals and user guides at all-guides.com Technische Daten 908 B / 908 D / 908 B ew / 908 T ew Wandlerprinzip dauerpolarisiertes Kondensatormikrofon Übertragungsbereich 40 – 20.000 Hz Richtcharakteristik Niere Freifeld-Leerlauf- 4,0 mV/Pa Übertragungsfaktor (1kHz) 0,56 mV/Pa ( 908 T ew) 100 Ω...
Seite 12
All manuals and user guides at all-guides.com * mit MZA 900 P ( 908 B / 908 D) 908 B ew / T ew zum Direktanschluss an ew-Sender Anschlussbelegung Stecker 908 B, 908 D 3,5 mm 3,5 mm 908 B ew, 908 T ew 3,5 mm...
Seite 13
All manuals and user guides at all-guides.com Übersicht Mikrofonanwendungen Modell Anwendung Gesang Chor Studio, akust. Instrumente Orchester Trompete, Posaune Saxophon Akustische Gitarre Akustischer Bass Gitarrenverstärker Bassverstärker Leslie Piano, Flügel Kick Drum Snare Drum Hänge-Tom Stand-Tom Congas Becken Percussion Overhead Konferenztisch, Altar Rednerpult Theaterbühne...
Seite 15
All manuals and user guides at all-guides.com Herstellererklärungen Garantie 2 Jahre Konformitätserklärung Sennheiser electronic GmbH & Co. KG erklären, dass dieses Ge- rät die anwendbaren CE-Normen und Vorschriften erfüllt. Akkus und Batterien Alte Akkus und Batterien bitte nur leer über den Fachhandel oder Batteriecontainer entsorgen.
Seite 16
All manuals and user guides at all-guides.com...
Seite 17
All manuals and user guides at all-guides.com 908 B / 908 D / 908 B ew / 908 T ew These microphones are professional pre-polarised condenser microphones. An extended dynamic range and a well balanced frequency response deliver an out- standing signal quality with excellent projection and the lowest possible distortion.
Seite 18
All manuals and user guides at all-guides.com Features Exceptionally vivid, clear sound Optimum positioning on the instrument due to flexible gooseneck Shock-mounted capsule provides low sensitivity to impact and handling noise Rugged metal body Extremely robust connection cable Can optionally be used with any evolution bodypack transmitter or the MZA 900 P phantom power adaptor Delivery includes...
Seite 19
All manuals and user guides at all-guides.com Positioning the microphone Wind instruments ( 908 B / 908 B ew / 908 T ew) Position Resulting sound Commentary Reduced ambient Use the MZH 908 B noise clamp to attach the microphone to the bell of the instrument.
Seite 21
All manuals and user guides at all-guides.com Drums / Percussions ( 908 D) Position Resulting sound Commentary More fundamental, Position on the little overtones drum: 3–5 cm above the drumskin, directed towards the center of the drumskin, the fundamental to Less fundamental, overtones ratio can many overtones...
Seite 22
All manuals and user guides at all-guides.com Attaching the drum clamp to the drum Drums / Percussions ( 908 D) Position Commentary To attach the MZH 908 D drum clamp, snap it onto the rim of the drum as follows: Put the upper part of the clip (1) onto the rim and clip on by pushing down in a rota- ting action (2) until it clips into place.
Seite 23
All manuals and user guides at all-guides.com Optimum positioning of the microphone The various adjustment possibilities of the MZH 908 D and MZH 908 B clamps together with the flexible goose- neck enable the microphone to be optimally positioned on the sound source (see arrows in the diagrams below). MZH 908 D MZH 908 B...
Seite 24
All manuals and user guides at all-guides.com Polar diagram 0° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 2000 Hz 125 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Frequency response curve - 30 - 40 - 50...
Seite 25
All manuals and user guides at all-guides.com Specifications 908 B / 908 D / 908 B ew / 908 T ew Transducer principle pre-polarised condenser microphone Frequency response 40–20,000 Hz Pick-up pattern cardioid Sensitivity 4.0 mV/Pa (free field, no load at 1 kHz) 0.56 mV/Pa ( 908 T ew) 100 Ω...
Seite 27
All manuals and user guides at all-guides.com * with MZA 900 P ( 908 B / 908 D) 908 B ew / T ew for direct connection to ew trans- mitters Pin assignment of connectors 908 B, 908 D 3,5 mm 3,5 mm 908 B ew, 908 T ew...
Seite 28
All manuals and user guides at all-guides.com Overview of microphone applications Modell Anwendung Vocals Choir Studio, acoustic instruments Orchestra Trumpets,Trombones Saxophone Acoustic guitar Acoustic bass Guitar amplifiers Bass amplifiers Leslie Piano, grand piano Kick Drum Snare Drum Rack toms Floor toms Congas Cymbals Percussion...
Seite 29
Manufacturer declarations Warranty 2 years Approval Sennheiser electronic GmbH & Co. KG declare that this device is in compliance with the applicable CE standards and regula- tions. Batteries or rechargeable batteries Please dispose of batteries or rechargeable batteries as special waste or return them to your specialist dealer.
Seite 30
All manuals and user guides at all-guides.com...
Seite 31
All manuals and user guides at all-guides.com 908 B / 908 D / 908 B ew / 908 T ew Ces sont des microphones professionnels de type électrostatique à polarisation permanente. La dynamique très étendue et la réponse en fréquence très régulière assurent un signal de haute qualité, d'une présence maximale, sans distorsion audible.
Seite 33
All manuals and user guides at all-guides.com Les cols de cygne longs et flexibles permettent un placement optimal des micros sur les instruments. Caractéristiques Son très vivant, d'une clarté exceptionnelle Placement optimal sur l'instrument grâce au col de cygne flexible Capsule à...
Seite 34
All manuals and user guides at all-guides.com Mise en place du microphone Instruments à vent ( 908 B / 908 B ew / 908 T ew) Positionnement Tonalité Commentaire Réduction du Utiliser la pince bruit ambiant MZH 908 B pour fixer le micro sur le corps de l'instrument.
Seite 35
All manuals and user guides at all-guides.com Batterie / percussions ( 908 D) Positionnement Tonalité Commentaire Beaucoup de son Positionnement sur fondamental, le fût : 3 à 5 cm peu de sons au-dessus de la harmoniques peau, en visant le milieu.
Seite 36
All manuals and user guides at all-guides.com Montage de la pince de fixation sur la batterie Batterie / percussions ( 908 D) Positionnement Commentaire Pour mettre en place la pince de fixation MZH 908 D, pincez-la sur le bord du fût comme suit : Guidez le loquet supérieur (1) sur le bord du fût, puis refermez la pince de fixation en...
Seite 37
All manuals and user guides at all-guides.com Placement optimal du microphone Les diverses possibilités de réglage des pinces MZH 908 D et MZH 908 B, alliées à la souplesse du col de cygne, permettent de placer le micro de façon optimale par rapport à...
Seite 39
All manuals and user guides at all-guides.com Diagramme polaire 0° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 2000 Hz 125 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Réponse en fréquence - 30 - 40 - 50...
Seite 40
All manuals and user guides at all-guides.com Caractéristiques techniques 908 B / 908 D / 908 B ew / 908 T ew Principe transducteur microphone électrostatique à polarisation permanente Résponse en fréquence 40–20.000 Hz Directivité cardioïde Sensibilité 4,0 mV/Pa (champ libre, à vide à 1kHz) 0,56 mV/Pa ( 908 T ew) 100 Ω...
Seite 41
All manuals and user guides at all-guides.com * avec MZA 900 P ( 908 B / 908 D) 908 B ew / T ew pour le raccordement direct aux émetteurs de la série ew Brochage des connecteurs 908 B, 908 D 3,5 mm 3,5 mm 908 B ew,...
Seite 42
All manuals and user guides at all-guides.com Vue d'ensemble des applications de microphones Modèle Application Chant Chœurs Studio, instruments acoustiques Orchestre Trompette,Trombone Saxophone Guitare acoustique Basse acoustique Ampli de guitare Ampli de basse Leslie Piano, à queue Grosse caisse Caisse claire Tom suspendu Tom sur pied Congas...
Seite 43
Déclarations du fabricant Garantie 2 ans Certification Sennheiser electronic GmbH & Co. KG déclarons que cet ap- pareil est en conformité avec les normes CE. Piles et accus Déposez les batteries usagées dans un point de collecte spéci- fique ou ramenez-les à votre revendeur.
Seite 45
All manuals and user guides at all-guides.com...
Seite 46
All manuals and user guides at all-guides.com 908 B / 908 D / 908 B ew / 908 T ew Questi microfoni sono microfoni a condensatore a polarizzazione permanente per uso professionale. La loro ampia estensione dinamica e la risposta armonica accuratamente sintonizzata offrono una qualità...
Seite 47
All manuals and user guides at all-guides.com Caratteristiche suono straordinariamente chiaro e vivace braccio microfono lungo flessibile l'orientamento ottimale sullo strumento insensibile al rumore dei passi e al rumore dovuto alla manipolazione grazie alla sospensione elastica della capsula corpo in metallo cavo antistrappo collegamento al trasmettitore tascabile evolution oppure all'adattatore di alimentazione del microfono...
Seite 48
All manuals and user guides at all-guides.com Posizionamento microfono Fiati ( 908 B / 908 B ew / 908 T ew) Posizionamento Risultato sonoro Commento Riduzione dei Fissare il microfono rumori circostanti con la clip MZH 908 B sulla campana dello strumento e orientarlo diretta- mente verso...
Seite 49
All manuals and user guides at all-guides.com Percussioni ( 908 D) Posizionamento Risultato sonoro Commento Molte fondamentali, Posizionamento poche armoniche sulla campana: 3 – 5 cm sopra la mem- brana, orientamento verso il centro della membrana. Il rap- porto delle note fon- Poche fondamen- damentali rispetto tali, molte armoni-...
Seite 51
All manuals and user guides at all-guides.com Fissaggio della clip per percussioni sulla campana Percussioni ( 908 D) Posizionamento Commento La clip per percussioni MZH 908 D viene fis- sata sui morsetti di chiusura della campana mediante un meccanismo a scatto. Per prima cosa, portare il dispositivo di chiu- sura a scatto superiore sul morsetto di chiu- sura (1) e far quindi scattare in posizione la...
Seite 52
All manuals and user guides at all-guides.com Posizionamento ottimale del microfono Le molteplici possibilità di regolazione delle clip MZH 908 D e MZH 908 B abbinate alla flessibilità del collo di cigno offrono la possibilità di posizionare il microfono in modo ottimale sulla sorgente sonora (ved. frecce nelle figure).
Seite 53
All manuals and user guides at all-guides.com Diagramma polare 0° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 2000 Hz 125 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Risposta in frequenza - 30 - 40 - 50...
Seite 54
All manuals and user guides at all-guides.com Dati tecnici 908 B / 908 D / 908 B ew / 908 T ew Principio di funzionamento microfono a condensatore a polarizzazione permanente Risposta in frequenza 40 – 20.000 Hz Caratteristica di direttività cardioide Fattore di trasmissione a 4,0 mV/Pa...
Seite 55
All manuals and user guides at all-guides.com * con MZA 900 P ( 908 B / 908 D) 908 B ew / T ew per il collegamento diretto al trasmettitore ew Assegnazione collegamenti spina 908 B, 908 D 3,5 mm 3,5 mm 908 B ew, 908 T ew...
Seite 57
All manuals and user guides at all-guides.com Panoramica degli utilizzi del microfono Modello Utilizzo Canto Coro Studio, strumenti acustici Orchestra Tromba, Trombone Sassofono Chitarra acustica Basso acustico Amplificatore per chitarra Amplificatore per basso Leslie Piano, pianoforte a coda Kick Drum (tam- buro a cornice) Snare Drum (cassa chiara)
Seite 58
All manuals and user guides at all-guides.com Dichiarazione del costruttore Garanzia 2 anni Certificazione Sennheiser electronic GmbH & Co. KG diachiara che questo ap- parecchio è conforme alle normative e alle prescrizioni CE ap- plicabili. Batterie e accumulatori Una volta scarichi, gli accumulatori esausti devono essere smaltiti nei negozi specializzati o in contenitori per la raccolta differenziata delle batterie.
Seite 59
All manuals and user guides at all-guides.com...
Seite 60
All manuals and user guides at all-guides.com 908 B / 908 D / 908 B ew / 908 T ew Estos micrófonos son micrófonos de condensador profesionales con polarización permanente. Su amplia dinámica y su respuesta de frecuencia cuidadosamente adaptada aseguran una señal de excelente calidad con una alta potencia y ausencia de distorsiones.
Seite 61
All manuals and user guides at all-guides.com Características Sonido extraordinariamente vivo y claro Brazo de micrófono largo y flexible para el posiciona- miento óptimo en el instrumento Insensible a ruidos de pasos y por manejo gracias al alojamiento elástico de la cápsula Carcasa metálica Cable resistente a la rotura Conexión a transmisores de bolsillo Evolution o a...
Seite 63
All manuals and user guides at all-guides.com Posicionamiento del micrófono Instrumentos de viento ( 908 B / 908 B ew / 908 T ew) Posicionamiento Resultado Comentario Reducción de los rui- Fijar el micrófono dos del entorno en el pabellón del instrumento con la pinza MZH 908 B y orientarlo directa-...
Seite 64
All manuals and user guides at all-guides.com Batería / percusión ( 908 D) Posicionamiento Resultado Comentario mucho tono funda- Posicionamiento en mental, pocos el tambor: 3 – 5 cm armónicos por encima del par- che, orientación al centro del parche. La relación entre el tono fundamental y los poco tono funda-...
Seite 65
All manuals and user guides at all-guides.com Fijación de la pinza para batería en el tambor Batería / percusión ( 908 D) Posicionamiento Comentario La pinza para batería MZH 908 D se abrocha en el aro tensor del tambor. Coloque primero la parte superior en el aro tensor (1) y encaje después la pinza para batería hacia abajo (2).
Seite 66
All manuals and user guides at all-guides.com Posicionamiento óptimo del micrófono Las múltiples posibilidades de ajuste de las pinzas MZH 908 D y MZH 908 B en combinación con el cuello de cisne flexible le permiten posicionar el micrófono de forma óptima en la fuente de sonido (ver flechas en las figuras).
Seite 67
All manuals and user guides at all-guides.com Diagrama polar 0° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 2000 Hz 125 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Respuesta de frecuencia - 30 - 40 - 50...
Seite 69
All manuals and user guides at all-guides.com Datos técnicos 908 B / 908 D / 908 B ew / 908 T ew Principio transductor Micrófono de condensador con polarización permanente Margen de transmisión 40 – 20.000 Hz Característica direccional ovalada Factor de transmisión de 4,0 mV/Pa campo acústico libre en...
Seite 70
All manuals and user guides at all-guides.com * con MZA 900 P ( 908 B / 908 D) conexión directa del 908 B ew / T ew al transmisor ew Asignación de terminales del conector 908 B, 908 D 3,5 mm 3,5 mm 908 B ew, 908 T ew...
Seite 71
All manuals and user guides at all-guides.com Vista general de las aplicaciones del micrófono Modelo Aplicación Canto Coros Estudio, instrumen- tos acústicos Orquesta Trompeta, Trombón Saxofón Guitarra acústica Bajo acústico Amplificador de gui- tarra Amplificador de bajo Leslie Piano, piano de cola Kick Drum Snare Drum Tam-tam...
Seite 72
Declaración del fabricante Garantia 2 años Autorización Sennheiser electronic GmbH & Co. KG declara que este aparato cumple las normas y directrices de la CE aplicables. Acumuladores y pilas Los acumuladores y las pilas usadas sólo se deben eliminar a través del comercio especializado o contenedores de recogida...
Seite 73
All manuals and user guides at all-guides.com...
Seite 75
All manuals and user guides at all-guides.com...
Seite 76
All manuals and user guides at all-guides.com 908 B / 908 D / 908 B ew / 908 T ew Deze microfoons zijn professionele permanent gepolari- seerde condensatormicrofoons. Hun grote dynamische bereik en het zorgvuldig afgestemde frequentie-bereik zorgen voor een uitstekende signaalkwaliteit met veel vermogen en minder vervorming.
Seite 77
All manuals and user guides at all-guides.com Eigenschappen buitengewoon levendige en heldere klank lange, flexibele microfoonarm voor een optimale uit- lijning op het instrument ongevoelig voor stap- en lichaamsgeluiden door veren- de kapsellagering metalen behuizing breukbestendige kabel aansluiting op evolution zakzender of microfoonvoe- dingsadapter MZA 900 P Omvang levering 908 D...
Seite 78
All manuals and user guides at all-guides.com Microfoon plaatsen Blaasinstrumenten ( 908 B / 908 B ew / 908 T ew) Positionering Klankresultaat Commentaar gereduceerde Microfoon met de nevengeluiden klem MZH 908 B op de trechter van het instrument bevesti- gen en direct op de geluidstrechter rich- ten.
Seite 79
All manuals and user guides at all-guides.com Slagwerk/percussie ( 908 D) Positionering Klankresultaat Commentaar veel grondtonen, Positionering bij de weinig boventonen trommel: 3 – 5 cm boven het vel, uit- lijning op het midden van het vel. De ver- houding van de grondtoon ten Weinig grondtoon, opzichte van de...
Seite 81
All manuals and user guides at all-guides.com De slagwerkklem op de trommel bevestigen Slagwerk/percussie ( 908 D) Positionering Commentaar De slagwerkklem MZH 908 D wordt op de spanband van de trommel bevestigd. Zet eerst de bovenste snapper op de span- band (1) en klem dan de slagwerkklem naar onder toe vast (2).
Seite 82
All manuals and user guides at all-guides.com Optimale plaatsing van de microfoon De veelzijdige instelmogelijkheden van de klemmen MZH 908 D en MZH 908 B in combinatie met de flexibele zwanenhals bieden u de mogelijkheid om de microfoon optimaal op de geluidsbron in te stellen (zie pijltjes in de afbeeldingen).
Seite 83
All manuals and user guides at all-guides.com Pooldiagram 0° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 2000 Hz 125 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Frequentiesnelheid - 30 - 40 - 50 - 60 - 70...
Seite 84
All manuals and user guides at all-guides.com Technische gegevens 908 B / 908 D / 908 B ew / 908 T ew Omvormerprincipe permanent gepolariseerde condensatormicrofoon Frequentiebereik 40 – 20.000 Hz Richtkarakteristiek nier Vrij veld-onbelast- 4,0 mV/Pa overdrachtsfactor 0,56 mV/Pa ( 908 T ew) 100 Ω...
Seite 85
All manuals and user guides at all-guides.com * met MZA 900 P ( 908 B / 908 D) 908 B ew / T ew voor rechtstreekse aansluiting op een ew-zender Aansluitbezetting stekker 908 B, 908 D 3,5 mm 3,5 mm 908 B ew, 908 T ew 3,5 mm...
Seite 87
All manuals and user guides at all-guides.com Overzicht van microfoontoepassingen Model Toepassing Zang Koor Studio, akoest. instrumenten Orkest Trompet, trombone Saxofoon Akoestische gitaar Akoestische bas Gitaarversterker Basversterker Leslie Piano, vleugel Kick-drum Snaardrum Hangende trom Staande trom Conga‘s Bekken Percussie Overhead Conferentietafel, altaar Spreekgestoelte...
Seite 88
Verklaringen van de fabrikant Garantie 2 jaar Vergunning Sennheiser electronic GmbH & Co. KG verklaren, dat dit toestel voldoet aan de toepasselijke CE-normen en voorschriften. WEEE-verklaring Breng dit apparaat aan het einde van zijn levensduur naar een van de plaatselijke verzamelpunten of naar een kringloopwin- kel.
Seite 89
All manuals and user guides at all-guides.com Sennheiser electronic GmbH & Co. KG 30900 Wedemark, Germany Phone +49 (5130) 600 0 Fax +49 (5130) 600 300 www.sennheiser.com Printed in Germany Publ. 04/07 511912/A01...
