Technical specifications

Input data
Input voltage
Frequency
Input voltage tolerance
Input current
Consumption
Output data
Output vollage U...
Output current
Residual ripple (100Hz
Operating data
Starting time
Operating temperature
Temperature coefficient
Storage temperature range
Efficiency
Cooling
Safety devices
Fuse recomended for input
Hold-up time
MTBF
Safety data
Test voltage transformer
High-voltage resistance
Air gaps and leakage paths
Degree of EMI suppression
Class of application
Ambient humidity
Protective class enclosure
6
115 V AC/230 V AC
45-66 Hz
+15% and –15%
115 V – max. 330 mA
230 V – max. 165 mA
max. 38 VA
see face plate
see face plate
< 2%
100%
-30 °C to +80 °C
<500 ppm / K
-30 °C...+105 °C
approx. 92%
selfcooling (S)
for 230 Volt - 0.25 A delayed
for 115 Volt - 0.5 A delayed
20 msec. Typical
>400.000 h
5 kV AC in accordance to
VDE0551
Primary circuit – secondary
Circuit 3.75 kV AC
acc. to VDE0806/IEC380
Primary circuit – secondary
circuit > 8 mm acc. to VDE0110
<K in accorddance to
VDE0875 and VDE0877
KSE according to DIN40040
95% rel. Humidity, yearly
Average dewing allowed for
use in tropical ambient
IP 40
Protective class terminals
Vibration proof
Applied construction regulations
according to VDE
IEC
EN
CSA/UL
Mechanics
Mounting
Dimensions
Weigth
IP 20 (VGB4)
>30 g at 33 Hz in X,Y and Z
acc. to IEC68 and DIN41640
VDE0100, 0113, 0551, 0160
804-8
IEC380, 742, 950
EN60950, EN50081, EN50082
CSA 22.2 UL1012
on rail to DIN46277 or
with screws
55 mm x 75 mm x 110 mm
approx. 0.8 kg
BA2048/04/05
