HOW IT WORKS

The Goal Zero Yeti Tank Expansion Battery integrates with a Goal Zero
Yeti Lithium or Yeti X Portable Power Station and Goal Zero Yeti Link
Expansion Module to increase your energy storage capacity. The Yeti
Tank is a chainable 100 Ah Lead-Acid Battery that adds an additional
1.2kWh to your home energy storage system.
Goal Zero Goal Zero Yeti Portable Power Station
Solar Panel Goal Zero Yeti Link Expansion Module
(Sold Separetely)
AC Wall
Outlet
REQUIRED (SOLD SEPERATELY)

HOW TO INSTALL

1. Properly install Goal Zero Yeti Link Expansion Module (sold
separately) into Goal Zero Yeti Lithium or Yeti X Power Station.
[Refer to Link User Guide for installation instructions.
2. Once Link is installed, connect the Male EC8 cable on the Tank to
the EC8 external battery connector on the Link.
3. If installing more than one, chain remaining Tanks by connecting
male to female cables on additional Tanks.
Master 8mm Input
for Yeti Link & Yeti Tank
Expansion Battery
EC8 External
Battery Connector
FRONT OF YETI
BACK OF YETI
4 4
FRONT OF YETI
Goal Zero Yeti Tank
Expasion Battery
BACK OF YETI
+
Male Chaining Cable
Yeti Tank
Expansion Battery
CHARGING YOUR YETI TANK
When Link and Tank are properly installed power passes through the 8mm
port to the Tank and then into the Yeti. The Input Charge Indicator light on
the Link will turn blue and the Lead Acid State of Charge Indicator light will
begin flashing green. NOTE: Upon plugin, all LEDs on the Link will turn on,
then off before correct lights are displayed. Power source will charge the
Yeti Lithium first. When the Yeti is fully charged, power will begin to store
in the Yeti Tank.
NOTE
The 8mm input port on the Yeti Link is the only way to charge both the Yeti
and Yeti Tank. Input ports on the Yeti display will only charge the Yeti, not
the Yeti Tank.
Ensure cable is fully inserted and tightly in place before use. Check
upon subsequent uses. For questions, contact Solutions Center at
support@goalzero.com or 1-888-794-6250
Tipping hazard - do not stack Tanks more than two high.
Male Chaining Cable
Female Chaining Cable
WARNING
5 5
