PLI-04
MEDIA DI BOX 2-CHANNEL FOR PC AND LAPTOP
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from
the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations).
Make certain that wall mounts are properly installed and secured. Make certain that
the equipment is installed securely and cannot fall down.
7. During installation, observe the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other
sources of heat. Make certain that the equipment is always installed so that is cooled
sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. Do not use this equipment in the immediate vicinity of water (does not apply to special
outdoor equipment - in this case, observe the special instructions noted below. Do not
expose this equipment to flammable materials, fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not
place containers filled with liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the
manufacturer.
15. Open the device for changing the battery, do not modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or
accidents, e.g., due to tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly
cause property damage and personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten
inside the equipment or if it has been damaged in another way, switch it off immediate-
ly and unplug it from the mains outlet (if it is a powered device). This equipment may
only be repaired by authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packag-
ing, please separate plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
22. If the equipment has been exposed to strong fluctuations in temperature (for example,
after transport), do not switch it on immediately. Moisture and condensation could
damage the equipment. Do not switch on the equipment until it has reached room
temperature.
23. Do not step on the power cord. Make certain that the power cable does not become
kinked, especially at the mains outlet and/or power adapter and the equipment con-
nector.
24. When connecting the equipment, make certain that the power cord or power adapter
is always freely accessible. Always disconnect the equipment from the power supply
if the equipment is not in use or if you want to clean the equipment. Always unplug
the power cord and power adapter from the power outlet at the plug or adapter and
not by pulling on the cord. Never touch the power cord and power adapter with wet
hands.
25. To disconnect the equipment from the power mains completely, unplug the power
cord or power adapter from the power outlet.
26. Unplug the power cord and power adapter from the power outlet if there is a risk of a
lightning strike or before extended periods of disuse.
CAUTION:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
There are no user serviceable parts inside. Have repairs carried out only by qualified
service personnel.
CAUTION – HIGH VOLUME LEVELS WITH AUDIO PRODUCTS!
This equipment is intended for professional use. Therefore, commercial use of this equip-
ment is subject to the respectively applicable national accident prevention rules and
regulations. As a manufacturer, Adam Hall is obligated to notify you formally about the
existence of potential health risks. Hearing damage due to high volume and prolonged
exposure: When in use, this product is capable of producing high sound-pressure levels
(SPL) that can lead to irreversible hearing damage in performers, employees, and audi-
ence members. For this reason, avoid prolonged exposure to volumes in excess of 90 dB.
MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at: http://www.
adamhall.com/media/shop/downloads/documents/manufacturersdeclarations.pdf
To request warranty service for a product, please contact Adam Hall GmbH, Adam-Hall-Str.1/
61267 Neu Anspach / Email Info@adamhall.com / 49 (0) 6081 / 9419-0
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that
this appliance may not be treated as household waste. This is to avoid environmental
damage or personal injury due to uncontrolled waste disposal. Please dispose of this
product separately from other waste and have it recycled to promote sustainable
economic activity.
© Palmer
Palmer is a brand of the Adam Hall Group
SCOPE OF APPLICATION
The PLI-04 was developed for special requirements in the media field.
It provides an easy way to connect PCs and other consumer devices with unbalanced
outputs to a professional PA system with balanced inputs, for the purpose of a presentation,
for example...
The PLI-04 is designed for stereo operation. A switch also allows for the mono playback on
both output channels.
As inputs, the usual jacks are available: TRS jack which accepts both mono and stereo
jack plugs, RCA socket and a 3.5 mm stereo mini jack input, e.g. in order to connect
headphone outputs from laptops. Outputs are provided for the customary XLR/m sockets
with transformer-balanced circuitry for professional equipment.
CONNECTORS
Connect the line outputs left/right of the device to be connected to the sound system
with the inputs of the PLI-04, using shielded cables and the appropriate connectors. On
computer sound cards, you can usually find RCA sockets with right and left separation
or a 3.5 mm stereo mini jack. On laptops, the output socket can often be used for head-
phones. This is frequently also a 3.5 mm stereo mini jack. With the existing volume knob
or by software, a level adjustment is possible. HiFi devices like CD players almost always
have RCA outputs.
A simultaneous usage of both inputs such as jack and RCA on one channel is not rec-
ommended due to potential interaction. The outputs of the PLI-04 are connected to the
microphone input of the mixer using a shielded balanced microphone cable. Two micro-
phone channels are necessary for stereo playback, and with the help of the panoramic
bridge, a channel is routed to the left, the other to the right.
IMPORTANT: When using a single channel, the channel with the red RCA socket should be
used since the grounding of the housing is done via its output jack.
MONO SWITCH
When pressed, a pressure switch, located between the two XLR output jacks, mixes a
mono signal from the stereo signal by means of a transfer matrix circuit. The output signal
is available on the two XLR sockets. In this way, you can use the PLI-04 as a split box and
split a mono signal to an input jack on both XLR outputs. However, the galvanic separa-
tion takes place only between input and output. The two XLR sockets are not galvanically
isolated from one another.
Ground Lift Switch
A galvanic (electrically conductive) connection between mains powered devices is usu-
ally undesirable because it can lead to so-called ground loop hum. This manifests itself
in low-frequency hums caused by compensation currents on the grounding. Also, when
connecting computers to external audio devices, there is a risk of noise, due to the high
frequency of computer currents on the grounding.
TECHNICAL SPECIFICATIONS
Product Type: line isolator
Type: passive
Number of Channels: 2
Number of Inputs: 5
Input Connectors: 3.5 mm TRS, RCA, 6.3 mm Jack
Input Type: unbalanced
Input Impedance: 3.5 mm TRS, RCA, 6.3 mm Jack
Max. Input Level: + 6 dBU
Outputs: 2
Output Connections: XLR
Output Type: balanced
Output Impedance: 600 Ohm(s)
Max. Output Levels: + 6 dB
Transformer balanced: yes
Ratio: 3.16 : 1
Frequency response: 20 - 20,000 Hz
Controls: ground lift, mono/stereo
Cabinet Material: sheet steel
Cabinet Surface: powder coated
Width: 142 mm
Depth: 95 mm
Height: 46 mm
Weight: 0.712 kg
