Installation

Option 1: Mount into the
The RoomPanel installs over a standard 2-gang U.S.electrical box.
Step 1: Install the Metal Bracket
Attach the metal bracket to the electrical box (as shown in the following
illustrations).
Screws:
6-32 x 3/4 in
Keep the
Step 2: Install the Security Latch (Optional)
Install the security latch to the RoomPanel so that it cannot be easily
removed from the mounting bracket after installation.
RoomPanel
Step 3: Connect the Cable and Install the RoomPanel
Push the RoomPanel gently into the metal bracket.
Electrical Box
Metal Bracket
facing up.
2-gang U.S.electrical box
Security Latch
