Antlion Audio ModMic Wireless Bedienungsanleitung

ModMic Wireless
Surface Choice
Find a flat spot on the headphones for the 0.5" circle of adhesive. The adhesive will stick to smooth and
mesh surfaces but does not stick well to rubberized surfaces.
1. Put the headphones on to ensure the ModMic will reach the corner of your mouth from the desired
mounting point.
2. Thoroughly clean and dry the surface with the included alcohol pad.
Attaching & Orientation
1. Connect a to the ModMic base via the magnet.
2. Remove the protective backing from the adhesive.
3. While holding the ModMic, orient the mic boom
angle down so it points towards where your mouth
will be when using your headphones. This will reduce
the need for additional bends in the boom after
installation (see figure A).
4. Press the whole mic/clasp down onto the cleaned
spot and hold firmly for 60 seconds. On mesh or
curved surfaces, allow the adhesive to cure for 1
hour.
5. For best results the ModMic Wireless is designed to
be attached to the right side of your headphones so
the charging port is facing down (see figure B).
For more information/extra clasps/questions/feedback visit www.AntlionAudio.com Designed in Portland, Oregon. Manufactured in China. ModMic and Antlion
The Bluetooth word mark is owned by Bluetooth SIG, Inc. aptX Low Latency word mark and logos are owned by Qualcomm Technologies International, Ltd. FCC
IDs: 2AP9OMICROPHONE , 2AP9ORECEIVER IC: 24071-MICROPHONE, 4071-RECEIVER"
www.AntlionAudio.com
logo are trademarks of GTDevice LLC. U.S. and International patents
Facebook: AntlionAudio
A
B
