Goobay 67920 Bedienungsanleitung

Fig. 1.
Technische Daten / Specifications / Spécifications / Specifiche / Datos técnicos /
Technische gegevens / Tekniske data / Tekniska data / Technická data / Dane techniczne
Item number
Input
Output AC
Max. AC continuous load
Dielectric strength
Optimal efficiency
Output DC
Protection level / Protection class
Connector 1, Type
Connector 2, Type
Connector 3, Type
Changeable Fuse
Operating height (ft over see level)
Dimensions
Weight (g)
Operating temperature (°F)
Storage temperature (°F)
Relative humidity (%)
Safety shut down @
Features
Verwendete Symbole / Symbols used / Symboles utilisés / Simboli utilizzati /
Símbolos utilizados / Gebruikte symbolen / Brugte symboler / Använda symboler /
Použité symboly / Stosowane symbole
For indoor use only
Alternating current
Direct current
Änderungen und Irrtümer vorbehalten.
REV2021-05-27
V2.0cl
Fig. 2.
67920
12-13.8 V
230 V , 50 Hz (mod. sinus wave)
150 W
300 W / 0.3 s max.
80 % (120 W)
5 V , 2.4 A max.
IP 20 / II
Car plug
Protective contact socket, (CEE 7/3)
USB A socket (4PIN)
T 20 A L 250 V
0-3048
166 x 84 x 68 mm
505 g
32 ~ 104
23 ~ 140
50 ~ 194
10 ~ 11 V or less, 15 ~ 17 V or more,
160 ~ 200 W cont. load and/or 130 ± 10 °C
- Short circuit and over current protection by fuse
- Cooled by fan and cooling fins
- Contact protection
- 1 -
Pillmannstraße 12 | 38112 Braunschweig | Germany
67920
T T 20 20 A A L L 250 250 V V
, 17 A
IEC 60417- 5957
IEC 60417- 5032
IEC 60417- 5031
Goobay® by Wentronic GmbH
