Key features
•
Expands your desktop PC with a 2.5" U.2 (SFF-8639) NVMe SSD to PCIe 3.0
•
PCI-Express base specification revision 3.0, 4 lanes
•
Fits in a PCIe x4, x8, x16 slot
•
Perfect for server, workstation and desktop PC
•
Supports U.2/PCIe 3.0 data transfer rates with up to 32 Gbit/s
•
Additional support for SATA III 6G drives
•
Supports SATA III data transfer rates with up to 6 Gbit/s
•
Supports the following operating systems: Windows®
System Requirements:
•
One available x4, x8 or x16 PCI-Express slot (PCI-Express Gen. 3.0, 4 lanes at least)
•
Internal free SATA 7 pin plug for SATA connection
•
Operating system: Windows®
•
The full U.2/PCIe 3.0 transfer rate can only be achieved with an installed NVMe U.2 drive
•
The IB-PCI2017-U2 is backwards compatible with PCIe 1.0 and 2.0
Note:
The IB-PCI2017-U2 adopts the PCIe Gen 3.0 x4 (32 Gbit/s) interface connector design. In order
to get 32 Gbit/s performances, please use a PCIe slot based on PCI-Express Generation 3.0, 4
lanes for card installation.
However, some PC systems do not support PCIe Gen 3.0 specification, so that IB-PCI2017-U2
cannot support full-power performance (32 Gbit/s). Please double-check with your PC system for
system detail information or accept the lower data transfer rates.
Installation
Important: During PCIe card assembly all cabling has to be disconnected from the computer.
Otherwise, it may cause electric shock accident or malfunction.
Pay attention to electrostatics when installing the PCIe card! A static charge on the body can cause
the unit to malfunction. Please touch a metal object to discharge or wear antistatic gloves before
installation.
Manual IB-PCI2017-U2
