INSTALLATION
1 Remove the air inlet grid.
Buckle
3 Remove the protective film
of the particle filter.
5 Install the pre-filter.
Align the slot position at the bottom, and
buckle up the upper U-shaped buckle.
10
2 Take out the pre-filter.
Press the raised part on both sides
to pull it outwards, and take out the
pre-filter.
4 Install the particle filter.
6 Install the air inlet grid.
Align the upper two buckles and
press them tightly, then press the
two sides at lower part, slowly and
gently buckle the air inlet grid.
Buckling
position
