Quick Reference Guide To Begin Unpack your Intimidator Hybrid 140SR V2 and make sure you have received all parts in good condition. If the box or contents appear damaged, notify the carrier immediately, not Chauvet. Intimidator Hybrid 140SR V2 QRG Rev. 5...
Power Linking For the maximum number of Intimidator Hybrid 140SR V2 products that you can power link at each voltage, see the User Manual or the sticker on the product. Warning! When power linking this product, lamp ignitions must be offset to avoid high inrush currents.
Seite 4
QUICK REFERENCE GUIDE Menu Map Refer to the Intimidator Hybrid 140SR V2 product page on www.chauvetdj.com for the latest menu map. Main Level Programming Levels Description Address 001–512 Sets the DMX starting address 19CH Selects DMX mode 13CH Slave Slave1–4...
DMX Linking The Intimidator Hybrid 140SR V2 can work with a DMX controller. Instructions for connecting and configuring this product for DMX operation are in the User Manual. If you are not familiar with DMX, download the DMX Primer from www.chauvetdj.com.
Seite 11
Reverse cycle effect, slow to fast No function 001 063 Gobo indexing Gobo Rotation 064 155 Rotation, fast to slow 156 231 Reverse rotation, slow to fast 232 255 Bounce, slow to fast Intimidator Hybrid 140SR V2 QRG Rev. 5...
Seite 12
Slow open, fast close. slow to fast Shutter 168 203 Fast open, slow close, slow to fast 204 239 Pulse strobe, slow to fast 240 247 Random strobe, slow to fast 248 255 Open Intimidator Hybrid 140SR V2 QRG Rev. 5...
Guía de referencia rápida Para empezar Desembale su Intimidator Hybrid 140SR V2 y asegúrese de que ha recibido todas las partes en buen estado. Si la caja o los componentes parecen dañados, notifíqueselo inmediatamente al transportista, no a Chauvet. Intimidator Hybrid 140SR V2 GRR Rev. 5...
Alimentación en cadena Para ver el máximo número de Intimidator Hybrid 140SR V2 que se pueden alimentar en cadena a 120 V o a 240 V, consulte el Manual de usuario o la etiqueta del producto..
GUÍA DE REFERENCIA RÁPIDA Mapa de menú Consulte la página del producto Intimidator Hybrid 140SR V2 en www.chauvetdj.com para ver el último mapa de menú. Nivel Niveles de programación Descripción principal Address 001–512 Configura la dirección inicial DMX 19CH Selecciona el modo de ejecución DMX...
Seite 16
Enlace DMX El Intimidator Hybrid 140SR V2 puede funcionar con un controlador DMX cuando se enlaza por conexiones serie DMX. Las instrucciones para conectar y configurar este producto para funcionamiento DMX están en el Manual de usuario. Si no está...
Seite 17
060 187 Indexación de color 188 219 Ciclo de color arco iris, rápido a lento 220 223 Parada 224 255 Ciclo de color arco iris inverso, lento a rápido Intimidator Hybrid 140SR V2 GRR Rev. 5...
Seite 18
111 114 Vibración gobo 1, lento a rápido 115 127 Abierto 128 189 Efecto cíclico, rápido a lento 190 193 Parada 194 255 Efecto cíclico inverso, lento a rápido Intimidator Hybrid 140SR V2 GRR Rev. 5...
Seite 22
Sin función 001 063 Indexación de gobo Rotación de Gobo 064 155 Rotación, rápido a lento 156 231 Rotación inverso, lento a rápido 232 255 Rebote, lento a rápido Intimidator Hybrid 140SR V2 GRR Rev. 5...
Seite 23
Cerrar lento, abrir rápido, lento a rápido Obturador 168 203 Cerrar rápido, abrir lento, lento a rápido 204 239 Estroboscopio de pulso, lento a rápido 240 247 Estroboscopio aleatorio, lento a rápido 248 255 Abierto Intimidator Hybrid 140SR V2 GRR Rev. 5...
Manuel de référence Préalable Déballez votre Intimidator Hybrid 140SR V2 et assurez-vous que vous avez reçu toutes les pièces en bon état. Si la boîte et/ou son contenu semble endommagés, contactez immédiatement le transporteur, et non pas Chauvet. Intimidator Hybrid 140SR V2 MR Rév. 5...
éteignez complètement l'appareil en le débranchant ou en coupant le disjoncteur. Chaînage électrique Pour savoir combien de projecteurs Intimidator Hybrid 140SR V2 peuvent être chaînés entre eux au maximum sur du 120 V ou du 240 V, veuillez consulter le manuel de l'utilisateur ou l'étiquette sur l'appareil.
Seite 26
Limite le mouvement de panoramique et d'inclinaison pour Totem Mode l'installation en hauteur Limite le mouvement de panoramique et d'inclinaison pour la DOWN l'installation sur une surface ou sur le sol Sensitivity 001–100 Contrôle de la sensibilité au son Intimidator Hybrid 140SR V2 MR Rév. 5...
Affiche la durée restante dans le cycle de maintenance Chaînage DMX Le Intimidator Hybrid 140SR V2 peut fonctionner avec un contrôleur DMX lorsqu'il est relié par des connexions séries DMX. Les instructions pour la connexion et la configuration de cet appareil pour le fonctionnement en DMX sont indiquées dans le manuel d'utilisation.
Seite 28
MANUEL DE RÉFÉRENCE IRC-6 (Télécommande par infrarouge) Le Intimidator Hybrid 140SR V2 est compatible avec la télécommande infra-rouge (IRC-6) de CHAUVET DJ. Pour plus d'informations sur l'IRC-6 ou pour télécharger les instructions, rendez-vous à l'adresse www.chauvetdj.com. Gobos Roue de gobo statique Roue de gobo rotatif Pour le mode faisceau, définissez le roue de gobo rotatif sur 006 ...
Seite 29
103 106 Tremblement du gobo 3, lent à rapide 107 110 Tremblement du gobo 2, lent à rapide 111 114 Tremblement du gobo 1, lent à rapide 115 127 Ouvert Intimidator Hybrid 140SR V2 MR Rév. 5...
Seite 30
128 255 Mise au point automatique du Gobo 2 Zoom 000 255 Zoom arrière à zoom avant Effet dépoli 000 255 0 á 100% Gradateur 000 255 0 á 100% Intimidator Hybrid 140SR V2 MR Rév. 5...
Seite 31
216 231 Macro de mouvement activé par le son 6 232 247 Macro de mouvement activé par le son 7 248 255 Macro de mouvement activé par le son 8 Intimidator Hybrid 140SR V2 MR Rév. 5...
Seite 32
Tremblement du gobo 8, lent à rapide 087 090 Tremblement du gobo 7, lent à rapide 091 094 Tremblement du gobo 6, lent à rapide 095 098 Tremblement du gobo 5, lent à rapide Intimidator Hybrid 140SR V2 MR Rév. 5...
Seite 33
Mise au point automatique du Gobo 1 automatique 128 255 Mise au point automatique du Gobo 2 Zoom 000 255 Zoom arrière à zoom avant Effet dépoli 000 255 0 á 100% Intimidator Hybrid 140SR V2 MR Rév. 5...
Seite 34
Ouverture lente, fermeture rapide, lent à rapide Obturateur 168 203 Ouverture rapide, fermeture lente, lent à rapide 204 239 Stroboscope à pulsation, lent à rapide 240 247 Stroboscope aléatoire, lent à rapide 248 255 Ouvert Intimidator Hybrid 140SR V2 MR Rév. 5...
Schnellanleitung Start Packen Sie Ihren Intimidator Hybrid 140SR V2 aus und überprüfen Sie, ob Sie alle Teile unbeschädigt erhalten haben. Wenn die Verpackung beschädigt ist, benachrichtigen Sie umgehend das Transportunternehmen, nicht jedoch Chauvet. Intimidator Hybrid 140SR V2 SAL Rev. 5...
Trennschalter oder durch Herausziehen des Steckers aus der Steckdose. Serienschaltung der Geräte Informationen zur maximalen Anzahl der Intimidator Hybrid 140SR V2-Geräte, die bei 120 V oder 240 V in Serie geschaltet werden können, finden Sie in der Bedienungsanleitung oder auf dem Typenschild am Gerät..
Seite 37
SCHNELLANLEITUNG Menükarte Die neues te Menükarte finden Sie auf der Intimidator Hybrid 140SR V2-produktseite unter www.chauvetdj.com. Hauptfunktion Programmierebenen Beschreibung Address 001–512 Stellt die DMX-Startadresse ein 19CH Wählt den DMX-Modus aus 13CH Slave Slave1–4 Wählt den Slave-Modus 1, 2, 3 oder 4 aus Auto Wählt den Auto-Modus aus...
Zeigt die verbleibende Zeit bis zur nächsten Wartung an DMX-Verbindung Der Intimidator Hybrid 140SR V2 kann mit einem DMX-Controller betrieben werden, wenn eine DMX-Serienschaltung zum Einsatz kommt. Anweisungen zum Zusammenschluss und der Konfiguration dieses Geräts für den Betrieb im DMX-Modus finden Sie im Benutzerhandbuch.
Zusammenschluss und der Konfiguration dieses Geräts für den Betrieb im Master/Slave-Modus finden Sie im Benutzerhandbuch. IRC-6 (Infrarot-Fernbedienung) Der Intimidator Hybrid 140SR V2 ist vollständig kompatibel mit der Infrarot-Fernbedienung (IRC-6) von CHAUVET DJ. Weitere Informationen zur IRC-6 oder herunterladbare Anweisungen finden Sie unter www.chauvetdj.com.
Seite 40
Gobo 12 Shake, langsam bis schnell 071 074 Gobo 11 Shake, langsam bis schnell 075 078 Gobo 10 Shake, langsam bis schnell 079 082 Gobo 9 Shake, langsam bis schnell Intimidator Hybrid 140SR V2 SAL Rev. 5...
Seite 41
008 012 6-Facetten-Prisma Prisma 2 013 130 Rotationseffekt, langsam nach schnell 131 247 Umgekehrter Rotationseffekt, langsam nach schnell 248 255 6-Facetten-Prisma Fokus 000 255 Fokus, groß bis klein Intimidator Hybrid 140SR V2 SAL Rev. 5...
Seite 42
Prisma zurücksetzen 144 151 Fokus und Zoom zurücksetzen 152 159 Alle zurücksetzen 160 167 Shutter zurücksetzen 168 231 Keine Funktion 232 239 Lampe aus 240 255 Keine Funktion Intimidator Hybrid 140SR V2 SAL Rev. 5...
GUIDA RAPIDA Informazioni sulla Guida La Guida Rapida Intimidator Hybrid 140SR V2 contiene informazioni di base sul prodotto quali montaggio, opzioni menù e valori DMX. Per maggiori dettagli, scaricare il Manuale Utente dal sito www.chauvetdj.com. Esclusione di responsabilità Le informazioni e le specifiche contenute in questa guida possono essere modificate senza preavviso.
Consente di spostarsi verso il basso nell'elenco menù e di diminuire il valore numerico all'interno di una funzione <ENTER> Consente di attivare il menù visualizzato o impostare il valore selezionato nella funzione selezionata Intimidator Hybrid 140SR V2 GR Rev. 5...
Seite 48
GUIDA RAPIDA Mappa menu Fare riferimento alla per la mappa dei menu più recente pagina del prodotto Intimidator Hybrid 140SR V2 www.chauvetdj.com Livello Livelli di programmazione Descrizione principale Address 001–512 Imposta l'indirizzo DMX iniziale 19CH Seleziona la modalità DMX 13CH Slave Slave1–4...
Mostra il tempo residuo nel ciclo di manutenzione Collegamento DMX Intimidator Hybrid 140SR V2 può funzionare con un controller DMX quando collegato tramite connessioni seriali DMX. Le istruzioni per il collegamento e la configurazione di questa unità sono contenute nel Manuale Utente. Se non si ha familiarità...
Seite 50
Bianco freddo 054 059 Ultravioletto 060 187 Indicizzazione colori 188 219 Arcobaleno ciclico, da veloce a lento 220 223 Fermarsi 224 255 Arcobaleno ciclico inverso, da lento a veloce Intimidator Hybrid 140SR V2 GR Rev. 5...
Seite 51
Oscillazione gobo 1, da lenta a veloce 115 127 Aperto 128 189 Effetto ciclico, da veloce a lenta 190 193 Fermarsi 194 255 Effetto ciclico inverso, da lenta a veloce Intimidator Hybrid 140SR V2 GR Rev. 5...
Seite 52
128 255 Messa a fuoco automatica gobo 2 Zoom 000 255 Diminuire zoom a aumentare zoom Effetto frost 000 255 Da 0 a 100% Dimmer 000 255 Da 0 a 100% Intimidator Hybrid 140SR V2 GR Rev. 5...
Seite 53
Macro movimento attivazione sonora 4 200 215 Macro movimento attivazione sonora 5 216 231 Macro movimento attivazione sonora 6 232 247 Macro movimento attivazione sonora 7 248 255 Macro movimento attivazione sonora 8 Intimidator Hybrid 140SR V2 GR Rev. 5...
Seite 55
Nessuna funzione 001 063 Indicizzazione gobo Rotazione Gobo 064 155 Rotazione, da veloce a lenta 156 231 Rotazione inversa, da lenta a veloce 232 255 Rimbalzo, da lento a veloce Intimidator Hybrid 140SR V2 GR Rev. 5...
Seite 56
168 203 Apertura veloce, chiusura lenta; da lento a veloce 204 239 Stroboscopio a impulso, da lento a veloce 240 247 Stroboscopio casuale, da lento a veloce 248 255 Aperto Intimidator Hybrid 140SR V2 GR Rev. 5...
Beknopte handleiding Om te beginnen Pak uw Intimidator Hybrid 140SR V2 uit en zorg ervoor dat u alle onderdelen in goede staat hebt ontvangen. Als de doos of inhoud beschadigd lijkt, stel dan de vervoerder onmiddellijk op de hoogte, niet Chauvet.
Power Linking Voor het maximale aantal Intimidator Hybrid 140SR V2-producten die via power link kunnen worden gekoppeld bij elke spanning, ziet u de gebruikershandleiding of de sticker op het product. Waarschuwing! Wanneer dit product via power linking wordt verbonden, moeten de lampontstekingen worden gecompenseerd om hoge ingangsstromen te voorkomen.
Seite 59
BEKNOPTE HANDLEIDING Menukaart Raadpleeg de productpagina van Intimidator Hybrid 140SR V2 op www.chauvetdj.com voor de nieuwste menukaart. Hoofdfunctie Programmeerniveaus Beschrijving Address 001–512 Stelt het DMX-startadres in 19CH Selecteert de DMX-modus 13CH Slave Slave1–4 Selecteert de Slave-modus 1, 2, 3 of 4...
Seite 60
Instructies voor het aansluiten en configureren van dit product voor DMX-bediening staan in de gebruikershandleiding. IRC-6 Infrarood Remote Control D Intimidator Hybrid 140SR V2 is compatibel met de IRC-6 infrarood afstandsbediening van CHAUVET DJ Ga voor meer informatie over de IRC-6 of downloadinstructies naar www.chauvetdj.com.
Seite 62
Gobo 2 schudden, langzaam tot snel 111 114 Gobo 1 schudden, langzaam tot snel 115 127 Open 128 189 Cyclus-effect, snel tot langzaam 190 193 Stop 194 255 Cyclus-effect omkeren, langzaam tot snel Intimidator Hybrid 140SR V2 BH Rev. 5...
Seite 63
Autofocus gobo 1 128 255 Autofocus gobo 2 Zoom 000 255 Zoom uit tot zoom in Frost effect 000 255 0 tot 100% Dimmer 000 255 0 tot 100% Intimidator Hybrid 140SR V2 BH Rev. 5...
Seite 66
Cyclus-effect omkeren, langzaam tot snel Geen functie 001 063 Gobo indexeren Gobo-rotatie 064 155 Rotatie, snel tot langzaam 156 231 Rotatie omkeren, langzaam tot snel 232 255 Springen, langzaam naar snel Intimidator Hybrid 140SR V2 BH Rev. 5...
Seite 67
Langzaam open, snel sluiten, langzaam naar snel Sluiter 168 203 Snel open, langzaam sluiten, langzaam naar snel 204 239 Impulse flitsen, langzaam naar snel 240 247 Willekeurig flitsen, langzaam naar snel 248 255 Open Intimidator Hybrid 140SR V2 BH Rev. 5...
