Little Tikes Play@Home 656927MX1 Anbauanleitung

Adult assembly required / Le montage devra être effectué par un adulte /
Debe ser armado por un adulto
F - 23
656927MX1
1" Screw / Vis de 2,5 cm / Tornillo de 2,5 cm
N - 8
XIM656927-1 - 9/20
www.littletikes.com
2" Screw / Vis de 5,08 cm / Tornillo de 5,08 cm
www.littletikes.co.uk
O - 12
www.littletikes.nl
www.littletikes.pl
2 1 /
2
ENGLISH
4 IN 1 DELUXE PLAYHOUSE
Ages: 1 1/2 - 6 years
Please save sales receipt for proof of purchase.
WARNING:
ADULT ASSEMBLY REQUIRED.
Two adults are recommended for assembly of roof.
• Keep these instructions for future reference.
• Prior to assembly, this package contains small parts: hardware
which is a choking hazard and may contain sharp edges and
sharp points. Keep away from children until assembled.
• Falls onto hard surfaces could result in head or other serious
injuries. Never place on concrete, asphalt, wood, packed
earth or other hard surfaces. Carpet over hard floors may
not prevent injury. Always use protective surfacing on the
ground under and surrounding the playground equipment
according to the enclosed "Consumer Information Sheet
for Playground Surfacing Materials." Maximum fall height
protection up to 5 feet (1.5m) required.
• Place this product on level ground, at least 6' (2 m) away
from any object. Objects to be avoided include, but H
are not limited to, fences, buildings, garages, houses,
overhead branches, laundry lines or electrical wires.
• Instruct children on proper use of this product, only after
properly placed, and not in a manner other than intended.
• Adult supervision required. Do not leave children
unattended.
• This product is intended for use by children ages over
1 1/2 - 6 years.
I
• Limit 3 children.
• Only for domestic use. Outdoor.
MAINTENANCE
G
• Check all hardware twice monthly during the usage
period and tighten as required. It is particularly important
that this procedure be followed at the beginning of each
season. If these checks are not carried out, the toy could
overturn or otherwise become a hazard. Replace if they
are loose, cracked, or missing.
• Take this product indoors or do not use outdoors when
temperatures fall below 0°F (-18°C).
DISPOSAL
• Disassemble and dispose of equipment in such a manner
that no hazardous conditions, such as but not limited to,
small parts and sharp edges, exist at the time equipment is
discarded.
CONSUMER SERVICE
Milton Keynes MK8 0ES
TOLL-FREE NUMBER:
Bucks, UK
United States: Tel: +0 800 521 558
www.littletikes.com E-mail: support@LittleTikesStore.co.uk
1-800-321-0183 Monday - Friday
Australia
The Little Tikes Company
www.littletikes.com.au
2180 Barlow Road
Imported by MGA Entertainment Australia Pty Ltd
Hudson, OH 44236
Suite 2.02, 32 Delhi Road
E-mail: service@littletikescare.com
Macquarie Park NSW 2113
United Kingdom:
1 300 059 676
www.littletikes.co.uk
Printed in U.S.A. D.R.©2020 The Little Tikes Company
Little Tikes, MGA Entertainment (UK) Ltd
© The Little Tikes Company, an MGA Entertainment company. LITTLE TIKES® is a trademark of Little Tikes
50 Presley Way
in the U.S. and other countries. All logos, names, characters, likenesses, images, slogans, and packaging
appearance are the property of Little Tikes. Please keep this address and packaging for reference since
Crownhill
it contains important information. Contents, including specifications and colors, may vary from photos
depicted on package. Instructions included. Please remove all packaging including tags, ties & tacking
stitches before giving this product to a child.
Tools required (not included)
Outils Requis (non compris)
Herramientas Requeridas (no incluidas)
Decals
D'autocollants
Calcomanías
" Screw / Vis de 6,98 cm / Tornillo de 6,98 cm
Q
J
K
Q
P
C
A
E D
LIMITED WARRANTY
The Little Tikes Company makes fun, high quality toys. We warrant to the original purchaser that this
product is free of defects in materials or workmanship for one year * from the date of purchase (dated
sales receipt is required for proof of purchase). At the sole election of The Little Tikes Company, the only
remedies available under this warranty will be the replacement of the defective part or replacement
of the product. This warranty is valid only if the product has been assembled and maintained per the
instructions. This warranty does not cover abuse, accident, cosmetic issues such as fading or scratches
from normal wear, or any other cause not arising from defects in material and workmanship. *The
warranty period is three (3) months for daycare or commercial purchasers.
MINIMUM SIZE allowed is .2" high
U.S.A and Canada: For warranty service or replacement part information, please visit our website at
Updated 12.2.11 per Paul Madan (new spacing)
www.littletikes.com, call 1-800-321-0183 or write to: Consumer Service, The Little Tikes Company, 2180
Barlow Road, Hudson OH 44236, U.S.A. Some replacement parts may be available for purchase after
warranty expires—contact us for details.
Outside U.S.A and Canada: Contact place of purchase for warranty service. This warranty gives you
specific legal rights, and you may also have other rights, which vary from country/state to country/state.
Some countries/states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you.
Please keep this manual as it contains important information.
1
A
(Strongly
Recommended)
(Vivement recommandé
(Altamente recomendable)
1
Decal
D'autocollant
Calcomanía
• Align numbers when connecting walls A and B.
• Aligner les chiffres en joignant les murs A et B.
• Alinee los números cuando una la pared A con la B.
4
B
D
6
M
G
2
B
C
N x2 - 2" (5,08 cm)
5
E
F x23 - 1" (2,5 cm)
G
7
• Follow net attachment illustrations
exactly! Always make sure net is
attached completely. Make sure
the label on the net is along the
bottom edge.
• Respecter fidèlement les
instructions illustrées pour attacher
le filet ! S'assurer que le filet est
toujours complètement attaché.
Vérifier que son étiquette est bien
située sur la bordure inférieure.
• ¡Coloque la red siguiendo
exactamente las ilustraciones!
Asegúrese siempre que la red quede
sujetada por completo. Asegúrese
que la etiqueta de la red quede a lo
largo del borde inferior.
3
Decal
D'autocollant
Calcomanía
1
12 13 10 11 14 15
4
3
20
16
21
17
22 18
23
19
1 5 6 7 8 9 2
• Match up red mark on bottom of net with bump on
bottom of wall. Attach screws in the order shown.
• Le repère rouge en bas du filet doit correspondre à
la partie bosselée en bas du mur. Mettre les vis dans
l'ordre indiqué.
• Haga coincidir la marca roja en el fondo de la red con
la prominencia en la parte inferior de la pared. Fije los
tornillos en el orden que se muestra.
H
I
