fontastic Mima Bedienungsanleitung Seite 2

User Manual
Thank you for choosing a Fontastic
User Manual carefully and comply with the safety instructions.
Package Contents
2 x Wireless Headset Mima, Storage and Charging Case, Micro-USB Cable, 3x
Pairs of Earbuds (small, medium & large) , User Manual
Overview:
1. Microphone
2. Function Button
3. Charging Pins
4. Earbuds
5. Charging Status
Display
Getting Started
Charging the headset
Insert the headset into the charging case. Make sure that
pins are well connected. While charging, the LEDs will turn
red when charging and change to white and then turn off
when fully charged.
Charging the case
Connect the Micro USB cable, included with the headset,
to the charging case and to a power supply or USB port
on a computer to charge the battery of the case. 4 LED
lights display the charge of the battery as 25%, 50%, 75%
and 100% respectively. While charging the case, the
headset will also charge if placed inside.
Switching On/Off
Switch on: Hold the Function button for about 2-3 second.
Switch off : Hold the Function button for about 5-6 seconds.
Note: Both devices will turn off if the button is pressed on
either one while they are connected.
When Mima is switched on, its white LED will blink 2 times per
second for about 1 minute until it is connected.
During this time it will try to reconnect to the last paired device.
If it can't fi nd the device within this time it will enter into pairing mode and the LED
will alternate between red and white.
Pairing
The Mima Headset has to be paired with a Bluetooth
The headsets LED will blink alternating between red and white when it's ready to
pair.
1. Take out the Headsets from the charging case. They will automatically power
on and pair with each other. Now one of them switches to pairing mode to
connect to the Phone.
2. Search for "Mima" on your Bluetooth
with your device. When porperly connected, the LED blinks white and turns off
after pairing has been sucessfull.
Note: When set into th charging case the connection is disabled. When taken out
of the case they will automatically reconnect.
Note: If the headset cannot be connected within 3 minutes it will turn off on its
own.
Note: If the connection is interrupted you have to press the Function Button to
reconnect the headset.
Music Control
All of the music controls can be accessed by using only the function button in
diff erent ways.
Play/Pause: Tap the function button once.
Skip Backwards: Tap the function button 3 times.
Skip Forwards: Tap the function button 2 times.
Registered trademarks are the property of their respective owners. Improvement and changes of the technical specifi cations and other data's could be made without prior notice. Fontastic, by D-Parts Mobilphon & Zubehör GmbH ● Birkenweiherstr, 16 ● 63505 Langenselbold, Germany / V1_03_19
Wireless Stereo Headset „Mima"
® Product. Please read this
1
1
2
3
4
5
Funktionsknopf
® device before use.
®
device and select it to pair the headset
Hands-free control
Answer/Hang up Call: Tap the function button a once.
Decline Call: Hold the function button for a second when the call is inbound.
Switch Call between Headset and Phone: Hold the function button for two
seconds during a call. Audio output will be switched between your phone and the
headset.
Microphone On/Off : Tap the function button twice.
Re-Dial: When in standby, tap the function button 4 times. Your phone will call the
last dialed number.
Voice Commands: When in standby, hold the function button for 2 seconds.
2
Safety advice:
• Do not use the headset on high volume for perlonged periods of time.
• Be careful not to use headset in potentially dangerous situations.
• Do not use the headset while operating a vehicle.
• Never open the device.
• Never immerse the device in water, always protect it from moisture.
• Disconnect electronic devices from the power when not using them
for longer time.
• Do not use headphones if they show any visible damage
Technical Specifi cations:
Transmission Distance: 15 meters
Bluetooth ® Version: V5
Charging Time: 1 hour
Talking Time: 5 hours
Battery type: Li-Ion
Mode: HFP, HSP, H2DP, AVRCP
Supported Codecs: SBC, AAC
Battery capacity: 50mAh
Charging Case capacity: 550mAh
Charging case input: DC 5V/400mAh
Charging case output: DC 5V /40mAh
The company is not responsible for any damage due to improper operation. If you need
technical support, please contact our support team by e-mail at service@fontastic.eu.
We hereby declare, that this device carries the CE mark in accordance with the regulations
and standards. It conforms with the fundamental requirements of the (RED) 2014/53/EC, EMC
directive 2004/108/EC as well as the Low Voltage Directive 2014/35/EC.
Note on environmental protection:
After the implementation of the European Directive 2012/19/EC in the national
legal system, the following applies: Electrical and electronic devices may not be
disposed of with domestic waste. Consumers are obliged by law to return
electrical and electronic devices at the end of their service lives to the public
collecting points set up for this purpose or point of sale. Details of this are defi ned by the
national law of the respective country. This symbol on the product, the instruction manual or
the package indicates that a product is subject to these regulations. By recycling, re-using the
materials or other forms of utilising old devices, you are making an important contribution to
protecting our environment.
GB
