GB
Operating Instructions

Fan Heater

1. Important Information
Keep these instructions in a safe place and pass them on to
possible future owners.
• Use device for room heating within enclosed rooms only.
• Repairs and corrective measures may only be carried out by
skilled technicians.
• Disconnect the power supply in the event of fault (pull out
the device plug or switch off the fuse).
• Do not use this device next to the bathtub, shower,
washbasin or swimming pool.
• The device carries the symbol shown on the right,
which indicates that the heating device must under
no circumstances be covered with any objects.
• Children or persons who are not capable of operating the
device safely must not operate the heating device. Ensure
that children do not play with the device.
• Caution! Potential dangers can arise when the device
switches on automatically, e.g. devices which have been
covered or blocked by objects since they were last used can
cause fire.
• Do not operate the heating device in rooms where highly
flammable substances are used (e.g. solvents, etc.).
• Do not lay the connecting cable across the device.
2. Technical Device Description
Heat output: 2000 W Degree of protection: IP21
Connection voltage: 1/N~, 230-240 V, 50 Hz
Dimensions in mm: (W x H x D) 235 x 569 x 235
3. Installation
Do not cover the heating device with any objects; fire hazard!
The fan heater may only be used as shown, i.e. on a horizontal,
even surface. Using it on deep pile carpets is not permitted.
Please use caution when installing it in front of flammable
objects. The power plug must always be accessible.
Observe the minimum clearances.
4. Electrical Connection
The voltage information on the type plate must match the local
mains voltage.
The indicator lamp is lit, when the device is plugged in.
When the power cord of this device is damaged, it must be
replaced by a qualified person, in order to avoid risks.
HC 210 TSD
5. Operation
Start the heater by pressing the on/off button.

5.1 Setting the operating mode

Pressing the "Operating mode" button allows you to choose
between the following functions.
5.1.1 Automatic mode
The device heats at the high heating level. You can set the
temperature you want using the +/- buttons. The device
switches off automatically when the set temperature is reached
and back on again when the temperature falls below the value
set.
5.1.2 Fan mode
Fan on without heating.
5.1.3 Heating mode - low heating level
The device heats at 50% of the maximum heat output. The
temperature cannot be set.
5.1.4 Heating mode - high heating level
The device heats at the maximum heat output. The
temperature cannot be set. All of the valid settings made using
the buttons are confirmed by an acoustic signal. The settings
made last are saved as long as the device is plugged in.
5.2 Rotating mode
Pressing the "OSC" button switches rotating mode on and off.
The heater rotates by a total of 90° to the left an d right in fan or
heating mode.
5.3 Timer
Pressing the "Timer" (remaining time) button limits the heater's
operating time. If, for instance, "1HR" is set, the device
switches off after one hour has elapsed. It is only possible to
set full hours up to a maximum of 8 hours of remaining time.
Warning!
Depending on the size of the room, heat requirement and
thermostat setting, rooms may overheat if the heating is not
controlled. This can be dangerous for people who are not able
to leave the room as it gets too hot.
4
