Installing The Batteries In The Remote Control; Specifications - Party Light & Sound PLS1250USB-RC Bedienungsanleitung

4. 12V DC power input: Connect this input to a DC adaptor to power the unit (not supplied).
5. 230V Power supply: Connect the unit to the AC power outlet.
REMOTE CONTROL:
MUTE button: no sound
REPEAT/Random: Press the button to repeat the current track, all tracks or play random
tracks.
MODE: Press this button to switch between AUX, USB/SD, FM and Bluetooth inputs.
10-/10+: Press either of these buttons to go 10 tracks back or forward
EQ: Press this button to switch among all preset equalization modes
Previous: Press to go to the previous track. In FM mode, press to go to previous station
Next: Press to go to the next track. In FM mode, press to go to next station
Play/Pause: Press this button to play or pause the playing.
Volume: Press either of these buttons to adjust the master volume.
EQ: Press this button to switch among all the EQ modes
Number keys: Press these keys to enter numbers
IR REMOTE CONTROLLER
Please operate the remote control within a distance of 6m and 30° between the remote
and the appliance. Aim the remote at the sensor. Remove all obstacles between the remote and the sensor.
The remote control might not work properly if the sensor is exposed to strong sunshine.
If the remote control doesn't work properly, please check the batteries.

INSTALLING THE BATTERIES IN THE REMOTE CONTROL

⠗ Place the remote face down on a flat surface.
⠗ Push the compartment cover into the direction of the arrow.
⠗ Slide the battery compartment open.
⠗ Remove the old battery and install the new one (CR2032) with the plus (+) symbol facing up.
⠗ Gently slide the battery compartment closed. It locks automatically.
RECOMMENDATIONS FOR BATTERIES
This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in
accordance with your local regulations..
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
When the internal batteries are not to be used, remove them to avoid damage caused by battery leakage or corrosion.
ATTENTION: Danger of explosion if battery is incorrectly placed. Only replace by the same or equivalent type.
WARNING :Do not swallow the battery. Danger of chemical burns. Keep new and old batteries out of the reach of children.
If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of children.
If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact imme-
diately a doctor.

SPECIFICATIONS

Output Power ..................................................................................................................................... 2 x 25W
Power supply ................................................................................................................... 220-240V~ 50/60Hz
Consumption ............................................................................................................................................ 50W
Bluetooth frequency band....................................................................................................... 2402-2480MHz
Max. RF emission ............................................................................................................................16.31dBm
FM frequency band .................................................................................................................... 87.5-108MHz
Frequency Response .................................................................................................................20 – 20000 Hz
Input Sensitivity ...................................................................................................................................400mV
Signal-Noise-Ratio (S/N) ..................................................................................................................... ≥ 76dB
Impedance ..................................................................................................................................................8Ω
Microphone Input Sensitivity .................................................................................................................. 20mV
Dimensions ....................................................................................................................... 160 x 118 x 58mm
Weight ....................................................................................................................................................... 1kg
Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local author-
ities or your dealer about the way to proceed.
