EN

Using the USB port

•
Verify the device is fully charged.
•
The USB port is not intended for data transfer.
•
Do not connect memory sticks, MP3 player or
similar data storage external appliances.
1. Choose the USB charging cable (8) or a USB
cable suitable for your mobile device.
2. Connect the device to the device to be charged
using the connection cable.
3. Press the activation button (3). Charging will
start.
The display shows the remaining battery
capacity of the device in percent.
Note:
Recharge the device (see „Charging the device")
when the information disappears from the
display (1).
4. Disconnect the device from the external device
after charging (note the display on the con-
nected device).
Technic al
data
Model JS500
Item number 10792
USB charging cable 5 V DC / 2 A
input voltage
Output voltage USB: 2x 5 V DC / max. 2.8
A total
Jumper leads:
12 V DC / 350 A
Peak amps 1000 A (< 1.0 s)
For engine displace- Petrol:
ment up to 5000 cm³
Diesel:
4000 cm³
Power supply Rechargeable battery
(Li-ion)
15000 mAh / 55 Wh
Charging time approx. 5 h
Charging cycles > 1000
14 f1.mts-gruppe.com
Model JS500
Brightness 70 lumen
Dimensions 170 x 82 x 32 mm
Weight 430 g
Ambient temperature -20 ~ +60 ºC
Cleaning, c are
and mainte-
nance
Minimal care will ensure your device remains
functional for years.
•
Carefully wind the cable when storing the tool.
This will help prevent accidental damage to the
cable and the tool.
•
Clean the product with a soft, dry cloth.
•
Store the machine in a clean, dry place.
•
Check the product for damage before every
use.

Service

Should you have any questions regarding com-
missioning or operating in spite of studying these
operating instructions, or if a problem should oc-
cur against all expectations, please get in contact
with your specialist supplier.

Disposal

The packaging consists of non-contaminating
materials that you can dispose of at your local
recycling point.
Do not throw electrical appliances in with
domestic waste!
In accordance with European Directive 2012/19/
EC for waste electrical and electronic equipment
(WEEE) and conversion to national law, used elec-
trical appliances must be collected separately and
taken to a recycling point. For ways to dispose of
old electrical appliances please contact your com-
munity or city administration.
