30132 AE stand fan IM LO-A 1/3/07 4:42 PM Page 12
WHEN USING FOR FIRST TIME /
OPERATING THE DEVICE
WHEN USING FOR FIRST TIME
•
Take all the device components out of the packaging
and remove all packaging material and enclosures.
•
Remove the screws from the rest foot parts.
Assemble the rest foot together in the shape of a
cross.
•
Place the pedestals with the rest foot connector onto
the assembled rest foot. Be careful to ensure the
holes in the connector are correctly aligned over the
screw threads of the rest foot.
•
Insert the screws through the holes and thereby
connect the rest foot to the pedestals. Ensure the
screws are screwed tightly. CAUTION: the screws
must not be canted!
•
Loosen the blocking ring by turning anti-clockwise
and then pull it completely away from the pedestals.
Insert the pedestal cover with the rectangular spaces
underneath and over the pedestals. Pull out the inner
tube. Now reposition the blocking ring over the
pedestals and turn it to secure it (clockwise).
•
Push the control firmly onto the inner tube. Use one
hand to keep the inner tube steady, to ensure that it
does not get pushed downward under the pressure.
Turn and secure the fixing screws in place.
•
Remove the rubber protection from the motor spindle
shaft. Screw in the retaining ring of the motor spindle.
•
Position the rear safety guard on the motor. Be
careful when doing so to ensure the vertical squares
of the safety guard are positioned over the plastic
nipples of the motor. Also ensure that the bore in the
area of the safety guard is pointing downward. Now
screw the retaining ring back onto the motor spindle
and ensure it is secured.
•
Now insert the impeller onto the motor spindle. Be
careful to ensure that the squares on the inner sides
of the impeller are positioned over the diagonally
situated splint of the motor spindle.
•
Screw the fixing screws of the impeller onto the
motor spindle. CAUTION: the fixing screws are
screwed in an anti-clockwise direction, namely to the
left! Keep the impeller secured while doing so.
Composite
C
M
Y
CM
MY
CY CMY
•
Place the front safety guard onto the rear safety
guard. To do so, attach a connector to the top of the
rear safety guard. Be careful when doing so to
ensure both the lower holes of the safety guard are
aligned. Insert screws in front through both holes and
secure these with the screw nut. Now lock the four
clamping devices in place to ensure both safety
guards are securely connected.
OPERATING THE DEVICE
1. Plug the device into the mains. The operating light
(POWER) lights up in red.
2. By loosening the blocking ring on the pedestals, the
inner tube can be adjusted to the desired height.
Subsequently, ensure the blocking ring is resecured in
place.
3. By loosening the side impeller screw under the
motor, the tilt angle of the impeller blades can be
adjusted. When you have reached the desired angle,
secure the impeller screw back in place.
4. The device offers the following functions:
• Slow speed
• Medium speed
• Fast speed
• Horizontal motor swing with impeller blade
5. Press the "on / speed" button. The fan starts at a low
speed. The speed can be altered by further pressing
the "on / speed" button. The chosen speed is then
indicated via a red light next to the specified speed,
namely "low" (slow), "mid" (medium) and "high" (fast).
6. The swing function is operated by pressing the
"swing" button. The swing function can only be
activated while the fan is in operation. Pressing the
"swing" button again stops the function. The fan
remains in the new setting.
12
K
GB
