Torro PROFI-EDITION Bedienungsanleitung Seite 7

[2]
[1]
[6]
[7]
[9]
[1]
Stromeingang
Main Power Input
[2]
Infrarot-Empfänger & Sender
Infrared Receiver & Emitter
[3]
LED Leuchte und Rückstoß
(Für Airsoft nur die zwei rechten Pins)
LED Flasher & Recoil
(Airsoft users for 2 right pins only)
[4]
Soundkartenanschluss
Sound Card Port
[5]
Empfänger Auswahl
Transmitter Selection
[6]
Motor rechts
Motor right
[7]
Motor links
Motor left
[3] [4]
[10]
[8]
Externer Empfänger Kanal 1-6
External Receiver Channel 1-6
[9]
Oberwanne 8-Pin-Stecker
Upper Hull 8-Pin-Plug
[10]
Rauchgenerator 2-Pin-Stecker
Smoke Unit 2-Pin-Plug
[11]
Panzer Rückleuchte
Tank Tail-Light
[12]
Lautstärkeregler
Volume Adjustment
[13]
Lautsprecher
Speaker
-7-
[8]
(nachrüstbar)
(upgradeable)
[5]
[12]
[13]
[11]
