Software Installation - AIPTEK MyNote Bluetooth Handbuch

MyNote Bluetooth Manual
e. Remove the battery compartment cover on top of the pen. Do
not attempt to open the pen itself. This may cause the pen to
malfunction.
f. Install two new SR41 batteries, with the positive poles facing up.
g. Close the battery compartment cover.
2. Refill the ink cartridge
Note:
The dimension of the pen cartridge is 2.3 ~ 2.4 mm (diameter) x 67 mm (length). You could buy them
at stationary shops or Aiptek webshop: www.aiptekshop.de.

Software Installation

Windows System:
1. Insert the Driver & Application CD into your CD drive and wait until the auto start window
appears. On Windows Vista and Windows 7 you may confirm the action by pressing
>>Continue<< if the User Access Control window appear.
2. Simply follow the steps on the screen and finish the installation of Note Manager.
MAC System:
1. Insert the Software CD into your CD drive and wait until the auto-starter is loaded.
2. Click on the tablet icon and simply follow the steps on the screen and finish the installation with
restarting your system.
After software is installed successfully, connect your MyNote Bluetooth with the USB cable to your MAC.
Your notes are now automatically transferred to you hard disk and stored as TIFF files in "documents"
folder.
For more details please refer to the PDF manual which you can find on the CD.
a. Detach the cap from the digital pen or use the pen tip remover.
b. Clamp the ink refill with the refill extractor. Hold the pen
firmly, and apply pressure with the extractor against it.
c. Pull the used refill out. Slide the new refill into the tip of the pen.
d. Gently press the new refill until it is lodged securely in the
pen.
www.aiptek.eu
EN
Page 7
