USX-MOUNT XML008-K-03 Bedienungsanleitung Seite 3

TV INTERFACE
200mm
[7.87in]
400mm
[15.74in]
600mm
[23.62in]
WALL PLATE
407mm
[16.02in]
237mm
[9.33in]
70mm
[2.76in]
FULLY ASSEMBLED MOUNT
435mm
[17.13in]
267mm
[10.51in]
697mm
[27.44in]
15mm
[0.59in]
100mm
[3.94in]
TOP VIEW - EXTENDED
Ø9mm
[Ø0.35in]
TOP VIEW - RETRACTED
429mm
[16.90in]
3-D
SIDE VIEW - EXTENDED
+5°
419mm
[16.50in]
-15°
61mm
[2.40in]
3
