Congratulations!
With your purchase you have decided on a
high-quality product. Get to know the product
before you start to use it.
Carefully read the following instructions
for use.
Use the product only as described and only
for the given areas of application. Keep these
instructions safe. When passing the product
on to a third party, always make sure that the
documentation is included.
Scope of delivery
1 x Bike basket (1)
1 x Brace (2)
1 x Handlebar bracket (3)
1 x Screw M5x25mm (4a)
2 x Screw M5x30mm (4b)
2 x Washer 5mm (5)
2 x Pads, thin (6)
2 x Pads, thick (7)
1 x Rope (8)
1 x Allen key (9)
1 x Instructions for use
Technical Data
Max. load: 5kg
Safety notes
• C AUTION: Only transport packaged food-
stuffs in this product.
• Only mount the bike basket to the handlebar
as described in the instructions.
• The handlebar bracket is designed for
handlebars with a diameter of 23mm (thick
pad, preinstalled) and 25.4mm (thin pad,
included).
• Ensure the bike basket is securely attached
prior to each ride.
• Never load the bike basket with loads
heavier than 5kg.
• Never exceed the bike's approved total
weight. The bike's handling performance will
change depending on the load inside the
bike basket.
• Never bend or pinch Bowden cables.
12
GB
• Never cover reflectors or lights.
• Do not modify the bike basket or mounting
bracket.
• O nly mount the handlebar basket in accor-
dance with the mounting instructions and
make sure that the end of the cord does not
protrude from the top of the handlebar holder
as such could cause injury.
• C heck that all the connecting elements are
secure before every trip.
Assembly
Fig. A:
Unfold bike basket (1).
Fig. B:
Bend the brace (2) and insert into the basket so
that the hook and loop fasteners on the brace
and on the basket meet.
Fig. C:
Slide brace into the left and right straps.
Fig. D:
Place the handlebar holder (3) around the
handlebar, thread the cord (8) from below
through the outer left feed on the handlebar
holder to set the handlebar, and thread the cord
from above through the outer right feed and pull
it tight. Then secure the cord using the Allen key
(9) with a screw (4a). Thereafter thread the cord
(8) from below through the next feed and then
from above through the remaining feed and pull
it tight again.
Fig. E:
Install the handlebar bracket with 2x washers
(5) and 2x screws (4b) on both ends, using the
Allen key (9) to tighten.
Fig. F:
When mounting the handlebar bracket, be sure
the screw is positioned correctly.
Insert the screws into the handlebar bracket as
shown with the tick mark.
Fig. G:
Slide bike basket onto handlebar bracket until it
locks in.
Fig. H:
To remove the bike basket press down on the red
button and slide off basket in the direction of the
arrow.
