Operating instructions

Car USB Adapter
Item no. 1217405
Intended use
The car USB adapter enables a USB power supply in vehicles.
It may only be connected to an 12 V or 24 V DC on-board network with negative battery pole
to the body and may only be operated in vehicles with this on-board voltage type. This may
only be operated inside and not outside the vehicle. Avoid contact with moisture at all costs.
Any other than the intended use described above might result in product damage and further-
more cause hazards such as short circuit, fire, electric shock etc.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Safety instructions
Please read the operating instructions thoroughly before use, they contain
important information on correct operation.
In case of damage caused by non-observance of these operating instructions,
the warranty gets void! We are not liable for any consequential damage!
We are not liable for property damage or injuries caused by improper use or
non-observance of safety instructions! Such circumstances will void the war-
ranty!
• Check the product before start-up for any damage. It may not be put into operation
in the case of damage.
• The unauthorized conversion and/or changing of the product is not permitted for
safety reasons.
• Please ensure correct starting up of the unit . Please follow the operating instructions.
• Avoid heavy mechanical loading of the product and do not expose to high tem-
peratures, strong vibrations, dripping or spray water.
• Never pour liquids over product. There is a high risk of fire. If liquid should enter
the inside of the device immediately unplug the device from the power supply and
contact a professional .
• Keep out of reach of children. Keep away from children.
• Observe all other safety instructions in each chapter of these instructions.
Operation
The overall capacity of the USB connectors amounts to 2.1A
The power consumption of all connected consumers may not exceed this
value.
• Stick the car USB adapter into the cigarette lighter socket of your vehicle.
• The operational display lights up as soon as the car USB adapter is supplied with power.
• The ignition of the vehicle must be switched on if the operational display does not light up.
• Plug the USB plug of your 5 V USB device to be connected into the USB connectors of the
car USM adapter.
Disposal
Electronic devices are recyclable material and should not be disposed of in the
household waste.
At the end of its service life, dispose of the product in accordance with applicable
regulatory guidelines.
Technical data
Operational voltage .......................................... 12 - 24 V/DC
Power consumption at a maximum charge ...... 1200 mA (at 12 V)
..........................................................................
Output voltage .................................................. 2 - 5 V/DC
Version 08/14
Overall capacity ................................................ 2.1 A
°
Measurements .................................................. 25 x 53 mm
Weight .............................................................. 17.4 g
Operational and storage conditions .................. -20 to +60 °C / 0-90% rH
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent
the technical status at the time of printing.
© Copyright 2014 by Conrad Electronic SE.
550 mA (at 24 V)
V1_0814_02/VTP
