Instructions for installation

1.5. Parts list for Medium S1620SV and Large S2020SV

Name
Base frame
Base frame
Base frame
Base frame ventilation aperture
Wall elements
Wall elements 935
Wall elements 510
Electrical element 935
Ventilation element 935
Corner posts
Corner post A
Corner post G
Corner post H
Roof elements
Roof element
Roof element
Roof frame
Roof frame
Roof frame
Roof rim
Roof rim
Corner covers
Inner roof corner trims
Inner roof corner trims
Inner corner trim
Outer corner covers
Outer corner covers
Outer corner covers
Pcs Dimensions
(mm)
S1620SV
1 1522x68x44
1 1992x68x44
1 1522x68x44
2 1900x935x75
2 1900x510x75
1 1900x935x75
1 1900x935x75
2 1949x85x45
1 1900x92x91
1 1900x92x79
1 2022x883x64
1 2022x687x64
1 1947x45x32
1 1522x45x32
1 1394x45x32
2 2058x95x15
2 1650x95x15
1 1868x18x15
2 1426x18x15
2 1018x20x20
2 1900x80x15
1 1900x67x15
1 1900x65x15
p. 8/14
Pcs Dimensions
(mm)
S2020SV
1 1947x68x44
1 1992x68x44
1 1947x68x44
4 1900x935x75
1 1900x935x75
1 1900x935x75
2 1949x85x45
1 1900x92x91
1 1900x92x79
1 2022x1112x64
1 2022x883x64
2 1947x45x32
1 1819x45x32
2 2058x95x15
2 2033x95x15
1 1868x18x15
2 1850x18x15
2 1018x20x20
2 1900x80x15
1 1900x67x15
1 1900x65x15
