Instructions for Use – Simplex
Standard Equipment
Stainless steel frame; comfortable bolster; water-permeable mesh; straps; lowering
system

Putting into Service

• Carefully remove the transport protection and the packaging.
• Keep the packaging material and small parts out of the reach of children to prevent
swallowing or choking.

Teaching the User

The user is taught how to use this device by trained staff who will reference these
Instructions for Use.

Adjustment Options / Features

Installing and removing the bath chair lift
To install the bath chair lift, simply place it on the sides of the bathtub with both
hands.
Important: When placing the bath chair lift on the bathtub, make sure the lifting arm
is secured. (Fig. 2)
To remove the bath chair lift, first secure the lifting arm. Then remove the bath chair
lift from the sides of the bathtub with both hands.
Lowering and lifting
Lower the bath chair lift using the lifting lever. Release the lifting arm from the catch.
(Fig. 2) Then swing the lifting arm over to lower the bath chair lift safely. Swing the lift-
ing arm back to raise the bath chair lift. (Fig. 3)
Attention: Regularly check the tightness of the knurled screw locking. When the lifting
arm is locked, the white safety plastic disk must always be positioned horizontally to
the lifting arm tube.

Technical Data

Simplex
Seat width
Bath width
Max. lowering height
Overall dimensions (l x w x h)
Weight
Max. user weight
16
32 cm / 12.6"
54 - 64 cm / 21.3 - 25.8"
35 cm / 13.7"
125 x 74 x 15 cm / 49.2 x 29.1 x 5.9"
8 kg / 17.6 lbs
25 kg / 55.1 lbs
2021-04
