VIDEO*
MICRO
HDR 1920*1080
25FPS 16:9
SD Card
16GB 156 min
32GB 322 min
64GB 652 min
128GB 1315 min
* Depends on SD card brand, model and class type. Data are approximate.
Video Resolution
HDR 1920*1080 25P 16:9
2560*1080 25P 21:9
2304*1296 25P 16:9
1920*1080 45P 16:9
1920*1080 25P 16:9
1280*720 50P 16:9
Photo Resolution: 4MP

INSTALLATION

1. Slide the suction cup bracket (17) in the designated location at the top of the camera
until it clicks into place. Make sure the suction cup lever is unlocked.
2. Clean the inner front windshield of the car and remove the protective film from the
bottom of the suction cup. Moisten the suction cup, place it on the inside of your
windshield and lock the cup using the lever. We recommend placing the Guardo
DASHCAM PRO on the right side of the rear view mirror. Make sure the camera is
mounted horizontal for the best view.
3. Adjust the bracket position by using the adjustment knobs.
4. Connect the USB cable (19) of the car charger (18) to the USB port (2) of the DASHCAM,
and insert the car charger into the cigarette lighter.
2560*1080 2304*1296
25FPS 21:9 25FPS 16:9
108 min 108 min
223 min 223 min
451 min 451 min
910 min 910 min
Capacity of 2 minutes
180 MB (188,874,752 bytes)
260 MB (272,760,832 bytes)
260 MB (272,760,832 bytes)
180 MB (188,907,520 bytes)
180 MB (188,874,752 bytes)
180 MB (188,907,520 bytes)
1.16 MB (1,220,608 bytes)
Illustration III
1920*1080 1920*1080
45FPS 16:9 25FPS 16:9
156 min 156 min
322 min 322 min
652 min 652 min
1315 min 1315 min
-7-
PHOTO*
1280*720
4 MP
50FPS 16:9
156 min 3660
322 min 7410
652 min 14835
1315 min 29735
