2 GAUGE OVERVIEW

7
10
1 Shoulder Strap Harness Point
2 Sealed, Waterproof Buzzer
3 LCD Display
4 Gauge On/Off Key
5 Voltage Activation Key
6 Multifunction Softkeys
7 Rolling Spring Holder
8 Handgrip
9 LED Indicators - Red (left), Blue (right)
10 Accessory Connection Point
11 Specialised Ribbing (for protection to EN61010)
12 Handle & Integrated Safety Trigger Switch
13 Earth Signal Voltage Return Connection Point
14 Quick Release Rechargeable Battery Pack
