CAUTION
: To avoid potential personal injury or property damage:
All 6 lag bolts
assembly. Ensure the wall plate assembly is securely fastened to the wall before continuing on
to the next step.
Solid Concrete Wall Installation
Min.
8"(203mm)
Mounting
Template
MUST BE firmly tightened to prevent unwanted movement of the wall plate
Concrete Wall
Anchor
3/8"
3/8"
(10mm)
(10mm)
DANGER
2.9"
(74mm)
6
