Installation Guide

1 . Installation Steps

EN
User Guide can be downloaded from: heating.danfoss.com.
1 . Installation must be done by an authorised
electrician .
2 . Remove and mount timer back plate direct to wall
or on wall box, and wire as required for application,
see fig . 1 & 2 .
3 . Locate hooks at top of timer into top of back plate,
lower into position and tighten retaining screws .
2 . Dimensions and Wiring
Dimensions, see fig . 3 . Wiring diagram, see fig . 4 .
4
TS710 & FP720
VISUS14F
Danfoss Heating Solutions
