Getting started - initial set up
1.
Using the RF cable supplied, connect the TV to the TV Aerial wall socket.
Connect the power cable to the Electrical outlet.
2.
Turn on the device with marked ON/OFF switch
3.
Insert the batteries supplied into the Remote control and press the Standby
button to power on the TV.
4.
You will now be welcomed with the initial set-up screen. If it does not appear, on
the remote control, please press [MENU] then 8-8-8-8 and the menu will appear.
Press OK on the remote control and tuning will start.
As part of our continuing eff orts to reduce energy consumption, we added
a new Ecohome feature (appears on the fi rst installation screen). This function
helps reduce energy consumption up 15% compared to other modes. The image
brightness is reduced using Ecohome mode. If this setting does not suit your
environment, you can choose from other modes (Note: the professional mode is
the optimal default mode, but consumes 15% more than the Ecohome).
Please select desired language, country and environment. Set LCN* to ON if you
want to arrange found channels by cable provider preferences (only applies to
DVB-C channels).
Press [OK] button to start the tuning process.
5.
In the next step select the type of digital broadcasting. You can choose between
DVB-T (terrestrial), DVB-C (cable) or DVB-S2(satellite). The analog channel will be
searched automatically, as most of the cable network includes analog channels.
6.
Select DVB-C if your TV is connected to a cable TV network. Keep all default
settings as it is recommended.Then press [OK] to start the search. If DVB-C
channels are not found, contact your network provider for the valid "Network
ID". Then perform a new search. Press the [MENU], select "Network ID" and enter
the network ID. Start your search by clicking [OK].
7.
Optional channel presets DVB-S2*: Select "Satellie" in the "Digital-type" in
the menu for the optional channel presets. Here you can choose between the
various satellites. Since selection completed, then the channel list of the exact
satellite will be available to be imported into your TV system. This take several
seconds. Confi rm with [OK] button on the remote control, to start scanning.
If you are missing channels, the reason for this is likely to be signal strength, you
should consider connecting signal booster and re-tuning the TV.
Tip:
If the TV fi nds some, but not all, of the Digital channels, the TV is functioning cor-
rectly but the signal being received is not strong enough. (The signal strength
needs to be above 85% - you can see the signal strength the TV is receiving
when you change channels/ programmes) you will need to increase the signal
reception in order to receive all of the channels available. The most economical
way to do this is by purchasing and connecting a 'signal booster' in between the
TV and the TV aerial socket. If this does not solve the problem, you will need to
upgrade the TV aerial to a digital hi-gain compatible aerial.
* - Only for models with DVB-S tuner - see Technical specifi cation
