Axis PS-24 Installationsanleitung Seite 5

Werbung

Verfügbare Sprachen

Verfügbare Sprachen

  • DEUTSCH, seite 7
PS-24 Mains Power Adaptor
3
AC & DC Output
(not used)
5
Voltage selector switch
(115V/230V)
1
Terminal connectors
(To camera)
Cable gland
The outdoor power supply contains two sets of terminal connectors to provide easy wiring for alarm inputs/outputs
Important!
• Warning - high voltage. Read through the instructions before starting the installation. The electrical connection
should be made by an authorized electrician. Please observe relevant national and local regulations for the
installation.
• AXIS PS-24 is designed to be part of an IT power system. Ground is not connected internally in the power
supply.
Cables
Power cable (not supplied)
Input cables (not supplied)
AXIS PS-24 Specifications
AC Input:
AC Output for 100-120VAC:
AC Output for 220-240VAC
PS-24 Mains Adaptor
3
4
5
1
2
6-12mm
10-14mm
(6) AC Input connector
(2) Terminal connectors
100-120VAC / 220-240VAC, max 800mA / 400mA, 80VA
24VAC, max 40VA at -20°C to +30° C or max 35VA at +31°Cto 50°C ambient temperature
24VAC, max 50VA at -20°C to +30° C or max 35VA at +31°Cto 50°C ambient temperature
6
AC Input
230VAC/115VAC
6
4
Power switch
ON(1) OFF(0)
2
Terminal connectors
(From camera)
Outer ring
Copper cables: AWG 16-18 or 1.5mm
2
AWG 16-28 or 1.5mm
cables
2
