Operating instruction
english
EPIC MC shielded module
®
Recommended mounting arrangement
Technical data
Materials Data
Insulation material
Colour
Temperature range
System
Characteristic system values
Data
Connection technology
Insulation stripping length
number
Clamping range
clampable cable diameter
Rated data according to VDE 0106 Teil 100
Rated current
Rated voltage
Connection torques
Shielded clip
PCB Terminal
Installation instructions
• Use wire end ferrules!
• Clamp braided shielding under clip!
• Observe tightening torques.
• Position module at far end of frame with connection side facing outwards.
Assembly drawing
EPIC MCB 4+shield Female module
®
Stripping dimensions (mm):
PC glass fibre reinforced
grey (similar to RAL 7032)
- 20 °C ... + 85 °C or -4 °F ... +185 °F
Screw connection
(see fig. below) Pole
4 + shielding
0,08 ... 1,5 mm
2
AWG 28 ... 16
0,08 inch to 0,27 inch of
shielding
1 A
30 V
max. 0,5 Nm
max. 0,2 Nm
Ordering data
TYP
MCS 4+shield Male module
MCB 4+shield Female module
Circuit diagramm
Circuit diagram
female module
EPIC MCS 4+shield Male module
®
Stripping dimensions (mm):
Part No.
10390600
10390700
male module
