Zenner MinoConnect Montageanleitung Seite 3

English
Installation instructions
MinoConnect/MinoConnectRadio
Short description of the universal ZENNER interface for mobile remote read-out
Introduction
The MinoConnect transmission device serves for
remote reading and configuration of the consuming
appliances respective M-Bus or radio systems either
by means of optohead, serial interface or via radio.
MinoConnect partially replaces the cable connection
between a serial device and a PDA/PC by a Bluetooth
connection.
Devices that can be connected via RS232 with SubD
9 Plug to a computer can now be connected to
MinoConnect. The further connection to the PC/PDA
is then via Bluetooth. To be able to use the device,
ZENNER MSS software must be used.
Walk-by application: It is possible to receive data
protocols with MinoConnectRadio without using
MSS-Software.
For reading and configuration of meters with radio
interface (e.g. wM-Bus) ZENNER offers various
software solutions (MeterReaderLight). Before first
commissioning of the device, please insert the two
supplied batteries (NiMH 1.2V min. 2.700 mAh) with
States and actions
For a better view, but also for the diagnosis and possibly error detection in a system, MinoConnect shows the
most important states and actions with 7 coloured LED:
LED Function
TxD Indicates that a data transmission from MinoConnect to the connected device is being carried out.
RxD Indicates that data are being sent from the connected device to MinoConnect.
3.3V 3.3 Volt are available at the pin for the external supply voltage (for ex. MinoHead).
7V
7 Volt are available at the pin for the external supply voltage (for ex. ZENNER Optical head).
Charge
Charging light. With a connected supply it lights until the batteries are fully charged.
The flashing Bluetooth LED displays that the device is paired with another Bluetooth device.*
Blue-
tooth
The constantly lighting LED displays, that the device is connected with another Bluetooth device.
Lights after power-on, the power LED signals by different flash frequencies the following modes:
2.4 seconds
Power
0.6 seconds
0.12 seconds
* Note: The flashing is only visible after a power cycle.
3
Bluetooth connection is established
No Bluetooth connection
Battery capacity low, reload immediately! This display also occurs when a connected
device requires too much power (for example: short circuit).
respect to the marked polarity into the battery com-
partment. Then charge the device about 5 hours.
Switching on
MinoConnect is turned on by a short press (approx.
2s) on the yellow button (until at least one LED is lit).
When switched on, the power LED flashes green.
Switching off
In the ON-state please press and hold the button
till the power LED light up again (about 3 seconds).
Then release the button.
Please note: The MinoConnect has an Auto Power
Off function. If during the time period the button is
not pressed and no commands are received, the de-
vice switches itself off automatically. By command,
the switch-off time can be set via the interface (only
with GMM).
