Scosche TuneIt FMTD3PRO Bedienungsanleitung

� S CDS CI-IE'
WITH USB CHARGER & FLEX-NECK
• Easy plug and play
• Universal 3.5mm headphone jack
• Flexible goose neck
• Easy to read LCD display
• 3 Presets for quick tuning
• Wide range frequency: 88.1 - 107 .9
Voltage Power: 12V DC Power
Frequency Response: 20Hz - 15kHz
Display: Reverse graphics backlight LCD
Channel Indication
1. 12V POWER PLUG'
2. AUX-IN 3.5MM INPUT
3. FLEXIBLE GOOSE NECK
4. 12 WATT (2.4A) USB PORT
5. MEMORY
6. SET
7. POWER
8. LCD SCREEN
9. SCAN DOWN
10. SCAN UP
"Vehicle 12v socket size may vary!
Questions?
Need help with your Product?
•
Call Customer Service at:
(BOO} 363-4490 x1
For complete warranty details, please visit us at
www.scosche.com or call (800) 383-4490
Please refer to Figure 1 above for location of numbered parts.
1. Plug the TUNEIT power plug (1) into the 12V socket or cigarette lighter on the vehicle. Adjust
the LCD display (8) to a suitable viewing angle by bending the goose neck (3). Ensure that the
TUNEIT is secured and connected properly to your 12V socket.
2. Plug the 3.5mm AUX-IN input (2) into the headphone jack on your portable device. The
TUNEIT's 3.5 mm input needs to be plugged into the portable device in order for it to transmit
music to the car stereo.
3. Use the power button (7) on the back of the UNIT to turn on and off.
4. Use the SCAN UP / DN buttons (1 O & 9) to adjust to the desired FM frequency on the unit.
Tune the FM frequency on your radio to the same frequency on theTUNEIT. The selected
5.
frecuency will be shown on UNIT's display (8).
6. Adjust the volume of the portable device to 75%. Ensure that volume output is not too loud
on the portable device as it may cause the audio to sound distorted. The music will be
transmitted from the TUNEIT to the car stereo through the FM channel selected.
NOTE: For the best result, choose an FM station that has a weak signal or no signal at all. The
weaker the signal the stronger the audio transmission from the TUNEIT.
Register your product online at
©2019 SCOSCHE INDUSTRIES, INC.
FM TRANSMITTER
FEATURES
• Connect to most portable devices
• Direct plug-in to most 12v sockets or
Cigarette lighter
• Easy to tune buttons
• USB 5V recharge to most mobile devices
• 12 Watt (2.4A) fastest-charge circuitry
SPECIFICATIONS
Input Interface: 3.5mm Auxiliary Input
Recharge Interface: 12W USB Port
Fuse protection: 3A Fuse (exchangeable)
<SUP ,;OFF POWER 0"1>
107. 9
FM MHz
CH3 MEM
<SDN @�MEM>
FLEX VIEWS
The LCD screen can be adjusted to the
desired viewing angle in any direction
by bending the
flexible supporting
tube (Figure 2) .
OPERATION
www.scosche.com/register
TU NE lr
FMTDaPRO
SET>
FIGURE
SI 300FMTD3PRO 4/19
2
