III.
Installation- Mid-Woofers
1. Choose mounting locations for your Chrome Component System
mid-woofers. Check for clearance behind the speaker mounting
locations, making sure the speakers will not interfere with any handles,
window cranks, door locks, or brackets. If the speakers are to be
mounted in the vehicle doors, check the operation of all
functions(windows, locks, and any other switches or hand cranks) to
make sure there is no obstruction. Be sure the mounting location and
the drilling of screw holes for mounting will not present a hazard to any
wires, control cables, fuel lines, fuel tanks, hydraulic lines, or other
vehicle systems or components. For rear deck installations, make sure
the speakers will not interfere with opening and closing the trunk.
2. If you are replacing an original factory speaker with a speaker that is
exactly the same size, you may not need to cut or drill any new holes or
run any additional wires. Simply connect the speakers, observing
correct polarity, and mount the speakers in the factory location, using
the original mounting cut-outs, screw holes and hardware. You
probably will not need the grilles and mounting rings for replacement
installations.
3. Use the supplied template as a guide to cut the proper diameter
mounting holes. Use the template or mounting ring to mark the
locations for the mounting screws and drill the holes with a 1/8"
diameter bit.
Grille
Mounting
Screws
3
e
Mounting
Surface
Speaker
Mounting
Ring
Door installation
® ®
Ultimate
Cut-out
Mounting
Holes
Sound
Screw
Clips
