Ø30
(Ø 1 3/16")
MIN. 150 mm - MAX. 160 mm
(min. 5 29/32" - max. 6 19/64")
MIN. 230 mm - MAX. 240 mm
(min. 9 1/16 - max. 9 29/64")
L. 1500 mm
(L. 4' - 11 1/16")
G 1/2"
GAS19
Ø18
(Ø45/64")
59
(2 21/64")
PRODOTTI CORRELATI / RELATED PRODUCTS
FRE74 - MIL91
80
(3 5/32")
MANUTENZIONE / MAINTENANCE
NON UTILIZZARE
Questi disegni sono proprietà di CEADESIGN SRL s.u. pertanto non potranno
essere utilizzati e/o comunicati a terzi, anche in forma parziale, senza preventiva
autorizzazione. CEADESIGN SRL s.u. si riserva il diritto di apportare modifiche ai
disegni al fine di migliorare il prodotto.
CEADESIGN SRL s.u. has the property rights on these drawings, therefore they
cannot be used and/or transferred to third party, even in partial form, without any
prior authorization. Furthermore CEADESIGN SRL s.u. reserves the right to apply
any change to these drawings in order to upgrade the product.
_ REV10
DESIGN
NATALINO MALASORTI
GAS19/GASTONE
AISI 316/L STAINLESS STEEL
Gruppo miscelatore esterno a parete
per vasca/doccia con doccino.
Maniglia e flessibile colorati
Wall mounted mixer set
for bath/shower, without built-in
part, with hand shower.
Colored handle and hose
acido clorico e muriatico
HCl
cloric and muriatic acid
acido fluoridrico
HFl
DO NOT USE
hydrofluoric acid
ipoclorito di sodio
NaClO
chlorine bleach
sapone a PH neutro
UTILIZZARE
PH
TO USE
7
neutral PH soap
