eWME -2020
2 7 .5 "
Verbinden
Kugellager 6802 2RS / 61802 2RS / 15x24x5 mm
Kugellager 6801 2RS / 61801 2RS / 12x21x5 mm
w w w . c o n w a y - b i k e s . c o m
EXPLO DED DRAWIN G & H ARDWARE
Set Description/
Art.-Nr.
Beschreibung
Motor bolt set/
1
0.281.082/8
Motorbolzenset
Horst link bearing set/
2
0.281.085/1
Kugellagerset Horst Link
Maxle Insert/
3
0.280.166/9
Maxle Insert
Derailleur hanger set/
4
0.280.931/7
Schaltaugenset
Main frame bushing set/
5
0.281.086/9
Kugellagerset Hauptrahmen
Rocker bushing set/
6
0.281.087/7
Kugellagerset Rocker
Shock bolt set/
7
0.281.083/6
Dämpferbolzenset
Werbung
Verwandte Anleitungen für Conway eWME
Inhaltszusammenfassung für Conway eWME
- Seite 1 -2020 EXPLO DED DRAWIN G & H ARDWARE 2 7 .5 “ Set Description/ Art.-Nr. Beschreibung Motor bolt set/ 0.281.082/8 Motorbolzenset Horst link bearing set/ 0.281.085/1 Kugellagerset Horst Link Maxle Insert/ 0.280.166/9 Maxle Insert Derailleur hanger set/ 0.280.931/7 Schaltaugenset Main frame bushing set/ 0.281.086/9...
- Seite 2 -2020 GREASE & TO RQ U E 2 7 .5 “ S C H MI ER S TO F F E & D R E H M O M EN T E Torque 8 Nm Torque 12 Nm Torque 12 Nm...
- Seite 3 -2020 EXPLO DED DRAWIN G & H ARDWARE 2 9 “ Description/ Art.-Nr. Beschreibung Motor bolt set/ 0.281.082/8 Motorbolzenset Horst link bearing set/ 0.281.085/1 Kugellagerset Horst Link Maxle Insert/ 0.280.166/9 Maxle Insert Derailleur hanger set/ 0.280.931/7 Schaltaugenset Main frame bushing set/ 0.281.086/9...
- Seite 4 -2020 GREASE & TO RQ U E 2 9 “ S C H MI ER S TO F F E & D R E H M O M EN T E Torque 8 Nm Torque 12 Nm Torque 12 Nm...
