Wireless Charging Tray | 241190-57-1
Mercedes C-Klasse (Seite 2 - 15)
Mercedes E-Klasse (Seite 16 - 27)
Mercedes C-Class (page 2 - 15)
Mercedes E-Class (page 16 - 27)
D
EINBAUANLEITUNG
Schwierigkeitsgrad
gering
Mercedes C-Klasse / C-Class (W204)
• Limousine (W204) 03/2007 - 11/2013
• T-Modell / Wagon (S204) 12/2007 - 03/2014
• Coupé (C204) 05/2009 - 06/2015
A
B
C
Ø 1,5mm² (rot / red)
Sachgemäße Installation unter Beachtung dieser Einbauanleitung erfor-
derlich. Achten Sie auf korrekte Anschlüsse. Verlegen Sie die Kabel so, dass
Sie weder geknickt, gequetscht oder beschädigt werden können. Sorgen
Sie dafür, dass sich die Kabel nicht in Gegenständen verfangen können.
Wir können keine Haftung für Schäden übernehmen, welche durch un-
sachgemäße Installation oder Nutzung verursacht wurden. Verwenden Sie
darum ausschließlich das mitgelieferte Montagematerial.
Technische Änderungen vorbehalten, alle Angaben ohne Gewähr.
Das „Qi" Logo ist Warenzeichen des „Wireless Power Consortium"
© 2019 · acv GmbH · Straßburger Allee 10-12 · 41812 Erkelenz
hoch
Ø 2,5mm² (blau / blue)
GB
INSTALLATION GUIDE
level of difficulty
low
Mercedes E-Klasse / E-Class (W212)*
• Limousine (W212) 03/2009 - 2012*
• T-Modell / Wagon (S212) 11/2009 - 2012*
• Coupé (C207) 05/2009 - 2012*
• Cabriolet (A207) 03/2010 - 2012*
* Nur für Modelle mit zuziehbarem
Ablagefach. Nicht kompatibel mit
E-Klasse Facelift Modellen (2013-2016)
* Only suitable for vehicles with a
retractable storage tray. Not compatible
with E-Class facelift models (2013-2016)
E-Klasse Ablagefach (Beispielabbildung)
E-Class storage tray (sample photo)
An appropriate installation in observance of these operating instructions
is necessary. Please make sure the wiring is arranged so it is not bended
or crimped due to the risk of cable break. Make sure that all connections
are correct. Route the cable away from moving parts, do not allow the
cable to be entangled, pinched or damaged in any way.
We will not be liable for damage due to improper installation or utilization.
Use the specified accessory parts to prevent product failure.
Subject to technical modifications; no responsibility is accepted for the
accuracy of this information.
The "Qi" symbol is a trademark of the "Wireless Power Consortium"
