6.
1.DESCRIPTION
This set (Ref. 54999) has been designed to fits on RUBI electric cu-
tters range.
The set includes (pag.58):
1.Laser Device
2.M4x12 screws (x2)
3.M4 washers (x2)
Laser device:
Tracer level Class 2 with collimator.
It Projects a red straight line over the work surface.
Do not immerse the laser Device into water
Power
Laser Class
Length wave
Accuracy
Range
Max. Height projection
Dimensions
Weight
Batteries
Batteries life
Work temperature
Spirit level:
Shows levelled position of the Machine.
When machine is properly levelled the bubble must be into the red
circle.
2.WAY OF USE
Push the red button to switch on/off the laser (fig.A).
Checks that the laser trace is aligned with the blade's trajectory in all
machine's long, if not see user's manual point 3.
Place the tile to cut on the table and switch on the laser.
The laser trace will show the tile cut.
English
TRANSLATION OF THE ORIGINAL
CHARACTERISTICS
4.M4 flat nut.
5.Spirit level
6.Hex key DIN 911 - 2,5 mm
7.Batteries AAA 1,5 V (x2)
2 mW
2
650 nm
45°±2°
1,6 m
25 mm
55 x 40 x71 mm
80 gr
2x AAA 1.5V
50 h (continuous)
-20ºC~+50ºC
