axing basic-line BZU 10-02 Betriebsanleitung Seite 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
BA_BZU-10-02.pdf | 2021-04-26
Technical improvements, changes in design, printing- and other errors reserved.
Technical data:
Type BZU 10-02
Input
Frequency range 254...294 MHz (D258...D290 | S15...S19) @ VHF selective
398...438 MHz (D402...D434 | S33...S37) @ UHF selective
5...2700 MHz @ broadband
Connector
Impedance
Return loss
Level measurement
Range 60...105 dBµV selectiv
80...125 dBµV broadband
Resolution 5 dBµV +/- 2.5dB
General
Operating voltage 9 VDC (PP3) *
Power consumption 630 mW (max.)
Current consumption 70 mA (max.)
Current consumption 10 µA (max.)
in standby
Dimensions 60 x 120 x 26 mm
(W × H × D) appr.
Comments * 9 V battery not included in delivery
Herewith AXING AG declares that the marked products comply with the valid
guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
BZU 10-02
F-female
75 Ω
> 10 dB
basic-line
CATV signal tester
Operation instructions
