All manuals and user guides at all-guides.com MM1500 15.4” TFT LCD DECKENMONITOR 15.4” TFT LCD OVERHEAD DISPLAY MONITOR PER AUTO DA 15,4 POLLICI BEDIENUNGSANLEITUNG/GARANTIEURKUNDE USER MANUAL/WARRANTY CARD MANUALE D’USO/CARTA DI GARANZIA...
All manuals and user guides at all-guides.com Index: - Sicherheitshinweise s. 3 - Montage s. 4 - OSD Funktion I s. 6 - Fernbedienung s. 8 - OSD Funktion II s. 9 - Beschreibung des Zubehörs s. 12 - Abmessungen s.
All manuals and user guides at all-guides.com Sicherheitshinweise 1. Drücken Sie nicht auf die Anzeigefläche des Monitors. 2. Spritzen Sie zum Reinigen keine Flüssigkeiten auf den LCD-Monitor. Verwenden Sie zum Reinigen nur das LCD-Monitorreinigungstuch. 3. Schließen Sie nur Komponenten und Zubehör an, das vom Hersteller geliefert wird.
All manuals and user guides at all-guides.com Montage Schritt 1: Vorsicht: Achten Sie auf die Ausrichtung der Haltevorrichtung. Anleitung zum Festschrauben der Haltevorrichtung. Anleitung zum Festschrauben des Monitors.
Seite 5
All manuals and user guides at all-guides.com Schritt 2: Befestigen Sie den Monitor am Fahrzeughimmel. Befestigungsplatte Dach himmel Schritt 3: Befestigen Sie den Monitor mit den Schrauben an der Haltevorrichtung.
All manuals and user guides at all-guides.com Installiert! OSD-Funktion Video-Bedientasten...
Seite 7
All manuals and user guides at all-guides.com 1. Einschalten: Durch Drücken dieser Taste schalten Sie den LCD-Monitor ein oder aus. 2. V1 Video-Eingang: 1. Drücken Sie diese Taste, um die Video-Daten der Video Quelle-1 wiederzugeben. 3. V2 Video-Eingang: 2. Drücken Sie diese Taste, um die Video-Daten der Video Quelle-2 wiederzugeben.
All manuals and user guides at all-guides.com Fernbedienung: Power (Einschalten): Durch Drücken dieser Taste schalten Sie den LCD-Monitor ein oder aus. Select (Auswahl): Durch Drücken dieser Taste wählen Sie zwischen der Quelle Video 1 und Video 2. Menu (Menü): Diese Taste dient zur Anzeige der Funktionsmenüliste. Die Auswahl einer Funktion der Liste erfolgt durch Drücken der Taste.
All manuals and user guides at all-guides.com Up (Nach oben): Drücken Sie diese Taste, um den Wert für die ausgewählte Funktion zu erhöhen. Down (Nach unten): Drücken Sie diese Taste, um den Wert für die ausgewählte Funktion zu verringern. Display (Anzeige): Hiermit wählen Sie den Anzeigemodus: 16:9/4:3/16:9 oder Full (Vollbild).
All manuals and user guides at all-guides.com Contrast (Kontrast): Regelt den Bildkontrast. Einstellbereich: 0 ~ 31 Sharpness (Bildschärfe): Regelt die Bildschärfe. Einstellbereich: 0 ~15 Hue (Farbton): Dient zum Einstellen des Farbtons. Einstellbereich: 0 ~ 62 Saturation (Sättigung): Dient zum Einstellen der Farbsättigung. Einstellbereich: 0 ~ 62...
Seite 11
All manuals and user guides at all-guides.com VIDEO 1 Default (Voreinstellung): Stellt die Werkseinstellungen des LCD-Monitors wieder her. DEFAULT (VX.XX) VIDEO 1 Display mode (Anzeigemodus): DIS PLAY MODE 16:9 Hiermit wählen Sie den Anzeigemodus: 16:9/4:3 16:9 oder Full (Vollbild). VIDEO 1 SAVE AND EXIT Save and Exit (Speichern und Beenden):...
Seite 12
All manuals and user guides at all-guides.com Video Source 2 Input:...
All manuals and user guides at all-guides.com Spezifikationen 15,4 Zoll TV-System für Fahrzeuge Auflösung: 1280 (H) x 800 (V) Anzeigebereich: 331,2 (B) x 207,0 (H) Größe: 15,4” TFT Bildhelligkeit: 450cd ( typisch) Reaktionszeit: Ansteigend: 9 ms (typisch) Abfallend: 16 ms ( typisch) Sichtwinkel: Oben=50°, Unten=50°...
Seite 18
All manuals and user guides at all-guides.com Content - Precaution: p. 18 - Installation: p. 19 - OSD function: p. 21 - Remote control function: p. 23 - Content of OSD function: p. 24 - Discription of accesories: p. 28 - Dimension: p.
All manuals and user guides at all-guides.com Precaution 1. Do not apply Pressure to the screen 2. Do not sprinkle any liquid to clean LCD. If you need to clean it, please use LCD Clean cloth. 3. Please do not add any parts or use any accessory which is not provided from the manufacturer.
All manuals and user guides at all-guides.com Installation Step 1: Attention: It’s directional for the mounting bracket. Instruction to fix the screw of the mounting bracket. Instruction to fix the screw of the monitor.
Seite 21
All manuals and user guides at all-guides.com Step 2: Fix the monitor on the car roof. Step 3: Fix the monitor on the iron mounting bracket with the screws.
All manuals and user guides at all-guides.com COMPLETED ! OSD function VIDEO control keys...
Seite 23
All manuals and user guides at all-guides.com 1. Power: When you push this button, it will Power ON or OFF the LCD. 2. V1 Video input: 1. When you push this button, it will show the picture from video 1. 3.
All manuals and user guides at all-guides.com Remote control function POWER: When you push this button, it will Power On or Off the LCD. SELECT: Select Video 1 or Video 2 Input, when you push this key. MENU: Show Function Menu List and Select the function on the menu, when you push this key.
All manuals and user guides at all-guides.com UP: When you push this button, it will increase the function that you selected. DOWN: When you push this button, it will decrease the function that you selected. DISPLAY: Adjust the display mode to 16:9/4:3/16:9 FULL. MUTE: Mute the audio.
Seite 26
All manuals and user guides at all-guides.com CONTRAST: Adjust the Contrast of the Screen Adjustment range: 0 ~ 31 SHARPNESS: Adjust the Sharpness of the Screen Adjustment range: 0 ~15 HUE: Adjust HUE Function Adjustment range: 0 ~ 62 SATURATION: Adjust the saturation of the picture Adjustment range: 0 ~ 62...
All manuals and user guides at all-guides.com VIDEO 1 DEFAULT: Return to the original setting of the LCD. DEFAULT (VX.XX) VIDEO 1 DISPLAY MODE: Adjust the display mode to 16:9, 4:3 16:9 or FULL. DIS PLAY MODE 16:9 VIDEO 1 SAVE AND EXIT: Save your personal setting and exit SAVE AND EXIT...
Seite 28
All manuals and user guides at all-guides.com Video Source 2 Input: Gelb an Gelb Rot an Rot Weiß an Weiß...
All manuals and user guides at all-guides.com Indice: - Misure di sicurezza: p. 33 - Installazione: p. 34 - Funzione OSD p. 35 - Funzione telecomando p. 38 - Contenuto della funzione OSD p. 39 - Descrizione degli accessori p. 42 - Dimensioni p.
All manuals and user guides at all-guides.com Misure di sicurezza 1. Non esercitare pressione sullo schermo. 2. Non usare detergenti liquidi per pulire lo schermo. Se è necessario pulirlo, uti- lizzare uno straccio pulito per LCD. 3. Non aggiungere componenti e non utilizzare accessori ad eccezione di quelli for- niti dal produttore.
All manuals and user guides at all-guides.com Installazione Fase 1 Attenzione: è direzionale per il supporto di montaggio. Istruzioni per serrare la vite del supporto di montaggio. Istruzioni per serrare la vite del monitor. Pannello anteriore...
Seite 37
All manuals and user guides at all-guides.com Fase 2 Fissare il monitor al tetto dell’auto. Staffa di montaggio Fase 3 Fissare il monitor sul supporto di montaggio in ferro con le apposite viti.
All manuals and user guides at all-guides.com COMPLETATO Funzione OSD Tasti di comando VIDEO...
Seite 39
All manuals and user guides at all-guides.com 1. Power: premendo questo pulsante, il display LCD viene acceso (ON) e spento (OFF). 2. Ingresso V1 Video: 1. Premendo questo pulsante, le immagini vengono mostrate sul video 1. 3. Ingresso V2 Video: 2. Premendo questo pulsante, le immagini vengono mostrate sul video 2.
All manuals and user guides at all-guides.com FUNZIONE TELECOMANDO POWER: premendo questo pulsante, il display LCD viene acceso (ON) e spento (OFF). SELECT: premendo questo pulsante, è possibile selezionare l’ingresso Video 1 o Video 2. MENU: premendo questo tasto, viene visualizzato l’elenco dei menu funzione ed è possibile selezionare la funzione desiderata del menu.
All manuals and user guides at all-guides.com UP: premendo questo pulsante, si incrementa il valore della funzione scelta. DOWN: premendo questo pulsante, si riduce il valore della funzione scelta. DISPLAY: consente di regolare la modalità del display su 16:9/4:3/16:9/FULL. MUTE: consente di rimuovere l’audio. Premendo questo tasto una seconda volta, la modalità...
Seite 42
All manuals and user guides at all-guides.com CONTRAST (CONTRASTO): Consente di regolare il contrasto dello schermo. Gamma di regolazione: 0 ~ 31 SHARPNESS (NITIDEZZA): Consente di regolare la nitidezza dello schermo. Gamma di regolazione: 0 ~15 HUE (COLORE): Consente di regolare la funzione HUE. Gamma di regolazione: 0 ~ 62 SATURATION (SATURAZIONE): Consente di regolare la saturazione...
Seite 43
All manuals and user guides at all-guides.com VIDEO 1 DEFAULT (IMPOSTAZIONE PREDEFINITA): Consente di ripristinare DEFAULT (VX.XX) l’impostazione originale del display LCD. VIDEO 1 DISPLAY MODE: DIS PLAY MODE 16:9 consente di regolare la modalità del dis- play su 16:9, 4:3, 16:9 o FULL. VIDEO 1 SAVE AND EXIT SAVE AND EXIT:...
All manuals and user guides at all-guides.com Specifiche tecniche Monitor per auto da 15,4 pollici Risoluzione: 1280 (H) x 800 (V) Area display: 331,2 (W) x 207,0 (H) Dimensioni: 15,4” TFT Luminosità: 450 cd2 (valore tipico) Tempo di risposta: Salita 9ms (valore tipico) Discesa: 16ms (valore tipico) Angolo visivo:...
Seite 50
All manuals and user guides at all-guides.com La Vostra garanzia Gentile Cliente, grazie per aver acquistato questo prodotto Audiovox, prodotto studiato secondo i più elevati standard di qualità e sottoposto a test rigorosi. Se utilizzato correttamente, esso funzionerà perfettamente per molti anni.
Seite 51
Congratulations! You have made a wise selection in becoming the owner of a Audiovox Mobile Video equipment. Due to high quality Audiovox products have earned an excellent reputation through the western world. And this high quality standard enables us to grant a 2-years warranty for Audiovox Mobile Video products.
Seite 52
All manuals and user guides at all-guides.com ARANTIEKARTE ARRANTY Typ/ Type Serien-Nr./Serial-No. Name und Anschrift des Händlers /Stempel Name and address of the dealer/stamp Käufer/Customer Name/Name Straße/Street PLZ, Ort /City Land /Country Kaufdatum / buying date Nur gültig in Verbindung mit Ihrer Kaufquittung! No warranty without receipt!
