Abus TVVR30004 Kurzanleitung Seite 30

7
To assign the address data automati-
cally, tick the DHCP box. The addresses
are then assigned automatically by
the router (provided this function is
supported). In this case, proceed from
point 13 onwards.
30
All manuals and user guides at all-guides.com
8
192.168.0.20 192.168.0.25
192.168.0.1
If your router does not assign the
address data automatically, then enter
the data manually as shown in the
following steps. The Screenshots shows
an example of devices to be connected
with corresponding IP addresses.
9
The first three positions of the IP
address must correspond to the de-
fault gateway value. The last position
specifies the device activated through
the default gateway (e.g. the recor-
der), and is defined individually for
each device. For example, enter xxx.
xxx.xxx.64 for recorder 64.
English
