Manual: EL-D100G / EL-D200G / EL-D800RB
• operation, the device should cool down
for about 15 minutes.
• As for troubleshooting, please check the
FAQ on our website www.laserworld.com

6. Warnings and other notices on the device

Laser radiation!
Avoid exposure
to beam.
Laser class 3b / 4
(EL-D800RB)
Caution of
radiation if cover
is removed

7. Device connections

DMX out
DMX in
trim pot for
music-sensitivity
page 6 / 17
Please read manual before operation
Use in enclosed spaces only!
DMX address
LED signal
micro
• Removal of the warranty label as well
as damages to the device caused by
improper handling, neglect of the sa-
fety instructions and service notes will
void the warranty.
fan
Output power
wavelength
model type
production
year
power supply
& consumption
connection for power
supply
