Operation elements and connections
The opening of the instrument for fuse replacement, for example, may
only be carried out by professionals. Prior to opening, the instrument has
to be switched off and disconnected from any current circuit.
The instrument may only be used under those conditions and for those
purposes for which it was conceived. For this reason, in particular the
safety references, the technical data including enviromental conditions
and the usage in dry environments must be followed.
When modifying or changing the instrument, the operational safety is
no longer ensured.
4.0 Operation elements and connections
1. LCD
2. Measurement
function selection
switch
3. Input socket for
measurement ranges
4. Ground connection
for all measurement
ranges
5. Input socket for
current measurement
range 10 A
28
5
1
2
4
3
