Operating instructions
Hard drive mounting frame 8.89 cm (3.5")
Item no. 1407914
This product is designed to securely mount one or two compatible SSD/HDD hard disks onto
a larger hard drive bay (8.89 cm / 3.5") on a computer. It can be used to mount 2 x 9.5 mm or
1 x 9.5 mm and 1 x 12.5 mm hard drives.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms,
must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged.
In addition, improper use can cause hazards such as short circuiting, fire, electric shock etc.
Read the instructions carefully and keep them. Make this product available to third parties only
together with its operating instructions.
This product complies with the statutory national and European requirements. All company names
and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Hard drive mounting frame
• 8 x hard disk mounting screws
Up-to-date Operating Instructions:
1. Open www.conrad.com/downloads in a browser or scan the
displayed QR code.
2. Select document type and language and enter the item number
into the search field. After submitting the query you can download
displayed records.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on proper
handling in this manual, we assume no liability for any resulting personal injury or
damage to property. Such cases will invalidate the warranty/guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become
dangerous playing material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts,
high humidity, moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed if
the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Also observe the safety and operating instructions of any other devices into which
the product is mounted.
• Warning! Static charge destroys electronic components
• Consult an expert when in doubt about operation, safety or connection of the device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
Mounting and connection
• Disconnect the power supply to your computer.
• View the "Technical data" section for information on the suitable HDD/SSD sizes and heights.
• Connect the hard disk(s) and mounting frame as illustrated using the mounting screws included
with the product. Make sure that the mounting frame and hard disk are properly aligned.
The sockets on the hard disk (for data transfer and power supply) need to remain accessible.
• 4 x case mounting screws
• Operating instructions
Mounting options
9.5mm
9.5mm
Mounting the hard drive(s)
These images are schematic and for assembly illustration purposes only. They do not
accurately depict the product.
Inserting into the drive slot
• Carefully insert the pre-assembled unit into a free 3.5" drive bay on your computer, ensuring that
all cables can be connected. Secure the unit in place using the included screws.
• Connect the data and power supply cables to the hard disk(s). Make sure no cables can come
into contact with the fan inside your PC.
• Switch on your computer and test whether the newly fitted components function correctly.
Maintenance and cleaning
Never use aggressive and abrasive detergents, rubbing alcohol or other chemical
solutions, as these could damage the housing or even impair the functioning of the
product.
• Disconnect the computer in which the product is mounted from the power supply before
cleaning.
• The product does not require maintenance except for occasional cleaning. Use a soft, antistatic
and lint-free cloth to clean the product.
• Do not immerse the product in water.
Disposal
At the end of its service life, dispose of the product according to the relevant statutory
regulations.
You thus fulfil your statutory obligations and contribute to the protection of the
environment.
Technical data
HDD/SSD sizes/heights: ..............................2 x 9.5 mm or 1 x 9.5 mm & 1 x 12.5 mm
Mounting slot dimensions ..........................8.89 cm (3.5")
Dimensions (W x H x D)...............................102 x 25 x 113 mm
Weight ............................................................62.2 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the
technical status at the time of printing.
© Copyright 2016 by Conrad Electronic SE.
12.5mm
9.5mm
B
B
B
B
C
(7 mm hard drives can be mounted)
B
B
B
B
V3_0216_02-DS
