Installation

Installing and Connecting the Charging Station

>1m
>3m
1m
10m
>1m
35cm

Position for the charging station as follows:

•
In a level spot out of direct sunlight
(The front end of the charging station must not be 5 cm higher or
lower than the back end.)
•
Within reach of a wall socket
(The low voltage cable is 10 m long.)
•
With at least 3 m in front of it and 1 m to each side
(Do not position in confined spaces in the operating area.)
The entire charging station must be inside the operating area as shown
in the figure.
