Device overview

4.1 Technical data

Short designation of device
Supply voltage
Power consumption
Battery service life
Protection type
Contamination degree
Ambient temperature
Dimensions (W x H x D)
Weight
Radio frequency
Receiver category
Typical radio range
Duty Cycle
Mode of action
Guidelines
38
RTD 61001-xx
2x 1.5 V LR03/micro/AAA
max. 50 mA
2 years (normally)
IP20
2
0 to 50 °C
86 x 86 x 24.6 mm / 32 mm
110 g (including batteries)
868.3 MHz/869.525 MHz
SRD category 2
250 m (in open air)
< 1 % per h/< 10 % per h
Type 1
2014/53/EU Radio installations

5 Commissioning

5.1 Teaching the device

In order be integrated into the Alpha IP System and to communicate with other de-
vices, the room control unit Display must be taught-in fi rst. The room control unit
Display is taught-in directly to the Alpha IP base station, or in conjunction with the
radiator thermostats, to the Alpha IP Access Point. In case of direct teaching-in,
the confi guration is done on the device itself; in case of teaching-in via the Access
Point, it is done via the Alpha IP app.

5.1.1 Teach-in without Alpha IP Access Point (stand-alone operation)

For teach-in, keep a minimum distance of 50 cm between the devices.
The teach-in process can be interrupted by shortly pressing the teach-in
key again. This is confi rmed by a short fl ash in red colour of the device
LED.
If no teaching-in is performed, the teach-in mode is fi nished automati-
cally after 30 seconds.
Commissioning
39
