2. Antenna: Keep the position of antenna at a 45° angle from vertical. Shown as below.
3. Audio connection: Connect the audio cable from the audio output on the receiver to the input on your
amplifier equipment.

OPERATION

Turn the receiver's volume to a minimum and turn on the microphone receiver.
If the RF LED light up directly, it means the receiver has interference from other signals or noise. First you must
disable the interference source before you can use this wireless microphone system. If no interference is
present, you can turn on the microphone by on/off switch.
Microphone and receiver are connected to channel A or B and RF LED on the receiver will light up directly.
Turn the volume control on the receiver slowly to the right sound level.
User tips:
1. You should always see the receiver antenna from your transmitter location.
2. The distance between transmitter and receiver should be as short as possible.
3. If the receiver has two antennas, they should be adjusted 45° with a vertical line.
4. Keep the antennas away from metal surfaces and shelter.
5. Let the antennas not contact or cross each other.
6. Before using the system during the presence of public do a test to find out where the "dead spots" are.
Avoid these spots when operational
No license required
BE DK F
HU IT NL
PT RO SI
CH GB
Belgium (BE), Denmark (DK), France (F), Finland (FI), Germany (DE), Hungary (HU), Italy (IT), Netherlands
(NL), Norway (NO), Poland (PL), Portugal (PT), Romania (RO), Slovenia (Sl), Spain (ES), Sweden (SE),
Switzerland (CH), United Kingdom (GB)
Please contact your radio licensing authority in your country, who will advise you on the available frequencies and
transmitter power requirements.
(excluding geographical restrictions)
FI DE
NO PL
ES SE
5
