Twintalker 9310
10 Description
1. Fixed antenna
2. LCD display
3. Connection for optional headset and charger
4. Menu button
– Enter the menu settings
5. On-off button
6. Microphone
7. UP button
– Increase the speaker volume
– Select the next value in the menu
8. Speaker
9. Down button
– Decrease the speaker volume
– Select the previous value in the menu
10. Call button
– Transmit a call tone
11. Push to talk button PTT

11 LCD display information

12 Using the Twintalker 9310
The display illustrations in next pages only show the icons or display
informations of the functions that are explained in the text.
8
TX icon - Displayed when transmitting a signal
RX icon - Displayed when receiving a signal
Speaker volume indicator
Lock icon - Displayed when the keypad is locked.
Battery charge level indicator
VOX icon - Displayed in Voice controlled (Vox) mode
Scan icon - Displayed when scan mode is active
Dual Scan icon - Displayed when dual scan mode is
active
1
11
10
9
Twintalker 9310
2
3
4
5
6
7
8
